99.999% Small Scale LNG Liquefaction Plants 365t/D ASME CE

99.999% Small Scale LNG Liquefaction Plant Associated Gas 365t/D​

Natural Gas (Associated Gas) Liquefaction and Separation Plants

Main Sizes:

50,000, 70,000, 100,000, 150,000, 200,000, 300,000, 500,000, 800,000, 1,000,000, 2,000,000 and 5,000,000 Nm3/d

SASPG’s 500,000Nm3/d project won the National Highest Quality Reward--Gold Medal

SASPG 2 million Nm3/day Plant in Erdos is the largest LNG plant built by Chinese Supplier

Now SASPG has a capability to liquefy 12million Nm3 natural gas per day.

1. Capacity 1) flow of natural gas incoming station 500,000Nm3/d

2) Liquefaction capacity 489,000Nm3/d

3) Venting acid gas 2,653Nm3/d

4) Turndown Ratio 50-110%

5) Continuous Operation Time ≥8,000h

6) Static Equipment Service Life 20 years

2. LNG Product Specifications 1) Output 365t/d (836m3/d) equivalent gas volume: 48.9 × 104Nm3/d 2) Temperature -161℃ 3) Storage Pressure 15kPa 4) Main Component CH4: 95.82%,C2H6: 2.69%,C3H8: 0.82%, N2: 0.53% 3. Side product heavy hydrocarbon 1) Output 2.1t/d(3.6m3/d) 2) Temperature 25℃ 3) Storage Pressure 0.6MPa 4) Main Component CH4: 2.08%,C2H6: 2.79%,C3H8: 7.3%,i-C4: 7.62%,n-C4: 46.85%,C5+: 33.36%
