BW-DKS-CP300-M2 PA-grade monocrystalline silicon pressure sensors
BW-DKS-CP300 Pressure Sensor adopts monocrystalline silicon sensor chip made of German advanced MEMS technology, and the world's original monocrystalline silicon double-beam suspension design, which achieves the international leading over-pressure performance and ensures the excellent stability of the signal. Embedded with the intelligent original imported pressure measuring diaphragm and signal processing module, it realises the perfect combination of static pressure and temperature compensation, which can provide high measurement accuracy and stability under a wide range of static pressure and temperature.
BW-DKS-CP300 Pressure Sensor is a pressure sensor that acts directly on the diaphragm of the sensor, causing the diaphragm to produce a micro-displacement proportional to the pressure, detecting this change with an integrated electronic circuit and converting the output to a standard measurement signal corresponding to the pressure.
| Model | Specification code | Clarification | |||||||
| BW-DKS-CP300 | PA Grade Monocrystalline Silicon Pressure Sensors | ||||||||
|
Range (Capsule) |
S2 ·········································· M1 ·········································· M 2 ·········································· M4 ·········································· L1 ·········································· L2 ·········································· |
6KPa 40kPa 100kPa 400KPa 4MPa 40MPa |
|||||||
| Shell connection thread |
N00 ······································ M45 ······································ G55 ······································ M56 ······································ M27 ····································· |
No M45*1.5 Thread G55*16 Thread M56*1.5 Thread M27*2 Thread |
|||||||
|
Isolation diaphragm |
SS ·································· HC ·································· TA ·································· GD ·································· |
SUS 316L Hastelloy C-276 Tantalum SUS 316L Gilt |
|||||||
| Filler fluid |
S ································· F · ································ O ································· |
Silicone oil Fluorine oil Vegetable oil |
|||||||
| Process Connection |
M20M ························· G12M ························ N12M ························ N12F· ························ |
M20 x1.5 External Thread G1/2 External Thread 1/2NPT External Thread 1/2NPT Internal Thread |
|||||||
| Pressure type |
- ··························· A ··························· |
Gauge pressure Absolute pressure |
|||||||
| Additional options | Please contact sales | ||||||||
