5-19mm Manufacturer PP Plastic Recycling Making Machine with Good Straightness and Lengths
Price:
Negotiable
MOQ:
1 SET
Delivery Time:
30-40days
Brand:
JIATUO CHINA
Product Description
5-19mm Manufacturer PP Plastic Recycling Making Machine with Good Straightness and Lengths
Technical Parameters of PP strap double output production machine
| Screw model | 90 |
| Number of strap | 2 straps |
| Width | 5-19mm |
| Thickness | 0.3-1.2mm |
| Screen changer | Automatic/Manual |
| Control system | PLC control(Chinese and English) |
| Production capacity | 125-150kg/H |
| Reducer Brand | GUOMAO |
| Motor Brand | GUGAO |
Product Description of PP strap production line
This PP strap band production line adopts high speed single screw sepcially used for the extruder, matching with different standard of sheet die and auxiliary device, it is used to extrude PP strap band. Production can use 100% recycled material to obtain a high add value commodity like strapping band.
The extrusion Line consist of the following parts
Screw extruder--Die head and mould(two strips)---Cooling water tank---First haul-off---Thermal oven---Second haul-off---Embosser---calibrating---haul off--winder
Feature of PP strap production line
1. High - Efficiency Production
designed with advanced extrusion and shaping technologies, enabling high - speed production. It can continuously extrude and form PP packing belts at a rate that significantly increases productivity compared to traditional production methods. For example, it can produce packing belts at a linear speed of 260m per minute, greatly shortening the production cycle and meeting the large - scale production demands of enterprises.
2. Excellent Product Quality
Using high - quality raw materials and precise control systems. The temperature control system in the extrusion process ensures that the PP material is evenly melted and extruded, resulting in packing belts with consistent thickness and width. This high - precision control makes the packing belts have excellent tensile strength and impact resistance, which can firmly bind various products during transportation and storage, reducing the risk of package breakage.
3. Energy - Saving Design
Adopting energy - efficient motors and advanced heating elements, the production line consumes less energy during operation. In addition, the optimized mechanical structure reduces friction and energy loss, making the production line more environmentally friendly and cost - effective in the long run.
1. High - Efficiency Production
designed with advanced extrusion and shaping technologies, enabling high - speed production. It can continuously extrude and form PP packing belts at a rate that significantly increases productivity compared to traditional production methods. For example, it can produce packing belts at a linear speed of 260m per minute, greatly shortening the production cycle and meeting the large - scale production demands of enterprises.
2. Excellent Product Quality
Using high - quality raw materials and precise control systems. The temperature control system in the extrusion process ensures that the PP material is evenly melted and extruded, resulting in packing belts with consistent thickness and width. This high - precision control makes the packing belts have excellent tensile strength and impact resistance, which can firmly bind various products during transportation and storage, reducing the risk of package breakage.
3. Energy - Saving Design
Adopting energy - efficient motors and advanced heating elements, the production line consumes less energy during operation. In addition, the optimized mechanical structure reduces friction and energy loss, making the production line more environmentally friendly and cost - effective in the long run.
FAQ
For PP(polypropylene) strapping band extrusion line
* What about the output of PP strapping band extrusion line? 120kg/hr, 260kg/hr, 380kg/hr.
* What about the size of strap that the PP strap machine can make? Width: 5-32mm; Thickness: 0.4-1.2mm;
* What about the installation power of the PP strap machine? 60kw/80kw/90kw/110kw;
