0-100A Portable Plasma Cutter With Built In Air Compressor 9KVA
Price:
Negotiate
MOQ:
100
Delivery Time:
4 WEEKS
Brand:
JONE
Product Description
JONE PLASMA SOUND PC 70/T 208 440V MAQUINA PARA SOLDAR PLASMA SOUND PC130T 208 440V 50 60 MAQUINA CUT-40
- JONE is an expert in Professional Plasma Cutting Machine, We have more than 20 years of experience for manufacturing variety pcba and welding machines. Our products include Plasma Cutting Machine, TIG Welding Machine, Wire Cut Machine & Laser Cutting Machine.
- A fast person can cut the stainless steel in 20-40 seconds. So fast! Say goodbye to the long wait for your cutting job. It is convenient for you to do other jobs since this Plasma Cutter is a one-man-manual machine, We will also provide special cutting handle to improve work efficiency by more than 10%
technical parameter
| Model | CUT-40C | CUT-60C | CUT-100C |
| Type | IGBT | IGBT | IGBT |
| AC Input Voltage(V) | 220V(110V can do) | 380V | 380V |
| Output current range(A) | 0-40 | 0-60 | 0-100 |
| Rated Input Power Capacity(KVA) | 6.2 | 10 | 9 |
| Input Frequency(Hz) | 20~40 | 20~60 | 30~100 |
| Non-load Voltage(V) | 300 | 300 | 300 |
| Rated Duty Cycle(%) | 60% | 60% | 60% |
| Efficiency(%) | 85% | 85% | 93% |
| Class of Insulation | F | F | F |
| Protection class of case | IP21 | IP21 | IP21 |
| Qualified cutting (mm) | 4mm-6mm | 6mm-10mm | 25mm-30mm |
| Quick joint Size | 10-25 | 10-25 | 35-50 |
| GW/NW(KG) | 19.5/23.5 | 34KG | 53KG |
| Machine Size(LxWxH mm) | 425*285*335 | 505*330*410 | 565*315*580 |
| Package(LxWxH mm) | 510*380*390 kraft paper box+ foam | 600*425*490 kraft paper box+ foam | 630*330*650 kraft paper box+ foam |
| 2m 16mm2300A clamp | 2m 125mm2 300A clamp | 2m 35mm2 500A clamp 2m 35mm2 500A holder | |
| Accessories | 4m AG-60 cutting gun | 4m P80 cutting gun | 4m P80 cutting gun |
| mask, brush, manual Relieve valve | mask, brush, manual Relieve valve | mask, brush, manual Relieve valve |
