Compact 200A Single Phase Tig Welding Machine CE Certification
Compact 200A Single Phase Tig Welding Machine CE Certification
Despite being a popular choice, electric welding is not the sole option when it comes to metal fabrication. TIG welding is actually a type of fusion in which an arch is formed between a non-fragile tungsten electrode and the metal being fused. The tungsten generates high temperature, has superior electrical characteristic and superior melting power as well as excellent mechanical properties. TIG welding provides ultimate fusion at lower temperatures than arc welding while requiring less current. This makes it ideal for applications such as joining pipes during manufacturing or joining steel plates during building construction.
If you are looking for welding machines that are specifically designed for a TIG welding, then this one is made just for you. You will get everything you need to make a proper connection between two or more parts.
technical parameter
| Model | TIG/MMA-200A |
| Type | IGBT 1PCB |
| Real Amp(A) | 160 |
| AC Input Voltage(V) | 220V(110V/220V can do) |
| Rated Input Power Capacity(KVA) | 7 |
| Input Frequency(Hz) | 50/60 |
| Non-load Voltage(V) | 56 |
| Output current range(A) | 20-200 |
| Rated Duty Cycle(%) | 60% |
| Efficiency(%) | 85% |
| Class of Insulation | F |
| Protection class of case | IP21 |
| Quick joint Size(mm) | 35-50 |
| Input power cable(m) | 1.8 |
| N.W./G.W.(kg) | 4.5/8.3KG |
| Machine Size(LxWxH mm) | 420*160*310 |
| Package(LxWxH mm) | 455*270*355 kraft paper box+ foam |
| Accessories | 1.8M 16mm2 200A holder |
| 1.2M 16mm2 300A clamp | |
| 4M WP-17 Black Torch | |
| Brush, Mask, Manual |
