Metal Mesh Perforted Stainless Steel Sheet 301 304 0.3mm 3mm Hole Duplex Plate
Metal Mesh 301 304 Thick 0.3mm 3mm Stainless Steel Sheet Hole Perforted Duplex Plate
Product Introduction
Stainless steel punching plate Uses: For through the urban area of highway, railway, subway, wall construction object, generator room, factory workshop, and other noise source acoustic noise reduction using sound-absorbing board, can be used in the structure of the ceiling, can be used for building stair, balcony, environmental protection furniture decoration orifice plate, can be used to shield of mechanical equipment, shopping malls shelf network, ventilation breathable mesh, etc. Features: Easy to process forming, various thickness of the plate, a variety of choice of aperture and arrangement, long service life.
|
Product Name
|
Perforated SS sheet
|
|
Grade
|
300 Series/400 series /200 series
|
|
Standard
|
JIS, AiSi, ASTM, GB, DIN
|
|
Length
|
customized
|
|
Width
|
500mm 1220mm 2000mm or customized
|
|
Place of Origin
|
China
|
|
Model Number
|
304 304L 316 316L 309 310s 410 430
|
|
Type
|
Plate
|
|
Application
|
Construction /Building /Industry or etc
|
|
Certification
|
SGS/BV/ISO
|
|
Tolerance
|
±5%
|
|
Processing Service
|
Bending, Welding, Decoiling, Punching, Cutting, or other customized
|
|
Product Name
|
perforated metal per price kg ss sheet stainless steel plate
|
|
Technique
|
hot rolled or cold rolled perforated punch
|
|
Surface
|
BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D
|
|
Price Term
|
CIF CFR FOB EX-WORK
|
|
Payment term
|
30%T/T Advance + 70% Balance,L/C
|
|
MOQ
|
1 Ton
|
|
Packing
|
Standard Sea-worthy Packing
|
|
Sample
|
Available
|
|
Stock
|
Available
|
|
Delivery time
|
7-15 days
|
| Description | Hole Size (mm) |
Pitch (mm) |
Open Rate | Sheet Thickness | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.4 mm |
0.5 mm |
0.8 mm |
1.0 mm |
1.2 mm |
1.5 mm |
2.0 mm |
2.5 mm |
3.0 mm |
4.0 mm |
5.0 mm |
6.0 mm |
||||
| R0.8 T2 | 0.80 | 2.00 | 15% | * | * | * | |||||||||
| R1 T2 | 1.00 | 2.00 | 23% | * | * | * | * | ||||||||
| R1.2 T2.25 | 1.20 | 2.25 | 26% | * | * | * | |||||||||
| R1.2 T2.5 | 1.20 | 2.50 | 21% | * | * | * | |||||||||
| R1.5 T2.75 | 1.50 | 2.75 | 27% | * | * | * | * | ||||||||
| R1.5 T3 | 1.50 | 3.00 | 23% | * | * | * | * | ||||||||
| R1.8 T3.5 | 1.80 | 3.50 | 24% | * | * | * | * | * | |||||||
| R2 T3 | 2.00 | 3.00 | 40% | * | * | * | |||||||||
| R2 T3.5 | 2.00 | 3.50 | 30% | * | * | * | * | ||||||||
| R2 T4 | 2.00 | 4.00 | 23% | * | * | * | * | * | |||||||
| R2.5 T3.5 | 2.50 | 3.50 | 46% | * | * | * | * | * | * | ||||||
| R2.5 T4 | 2.50 | 4.00 | 35% | * | * | * | * | * | * | ||||||
| R2.5 T4.5 | 2.50 | 4.50 | 28% | * | * | * | * | * | * | ||||||
| R2.5 T5 | 2.50 | 5.00 | 23% | * | * | * | * | * | * | ||||||
| R3 T5 | 3.00 | 5.00 | 33% | * | * | * | * | * | * | * | |||||
| R3 T6 | 3.00 | 6.00 | 23% | * | * | * | * | * | * | * | |||||
| R3.5 T5 | 3.50 | 5.00 | 44% | * | * | * | * | * | |||||||
| R4 T5 | 4.00 | 5.00 | 58% | * | * | * | |||||||||
| R4 T6 | 4.00 | 6.00 | 40% | * | * | * | * | * | * | ||||||
| R4 T8 | 4.00 | 8.00 | 23% | * | * | * | * | * | * | * | * | ||||
| R5 T7 | 5.00 | 7.00 | 46% | * | * | * | * | * | * | ||||||
| R5 T8 | 5.00 | 8.00 | 35% | * | * | * | * | * | * | * | * | ||||
| R5 T10 | 5.00 | 10.00 | 23% | * | * | * | * | * | * | * | * | * | |||
| R5 T2.5 | 5.00 | 25.00 | 4% | * | * | * | * | * | * | * | * | * | |||
| R6 T8.5 | 6.00 | 8.50 | 45% | * | * | * | * | * | * | * | |||||
| R6 T9 | 6.00 | 9.00 | 40% | * | * | * | * | * | * | * | * | ||||
| R6 T10 | 6.00 | 10.00 | 33% | * | * | * | * | * | * | * | * | * | * | ||
| R7 T10 | 7.00 | 10.00 | 44% | * | * | * | * | * | * | * | * | ||||
| R8 T8 | 8.00 | 11.00 | 48% | * | * | * | * | * | * | * | * | ||||
| R8 T8 | 8.00 | 12.00 | 40% | * | * | * | * | * | * | * | * | * | |||
| R8 T8 | 8.00 | 15.00 | 26% | * | * | * | * | * | * | * | * | * | |||
| R10 T13 | 10.00 | 13.00 | 54% | * | * | * | * | * | * | * | * | ||||
| R10 T14 | 10.00 | 14.00 | 46% | * | * | * | * | * | * | * | * | ||||
| R10 T15 | 10.00 | 15.00 | 40% | * | * | * | * | * | * | * | * | * | |||
| R10 T18 | 10.00 | 18.00 | 28% | * | * | * | * | * | * | * | * | * | |||
| R12 T16 | 12.00 | 16.00 | 51% | * | * | * | * | * | * | * | * | ||||
| R12 T17 | 12.00 | 17.00 | 45% | * | * | * | * | * | * | * | * | * | |||
| R15 T20 | 15.00 | 20.00 | 51% | * | * | * | * | * | * | * | * | * | |||
| R15 T21 | 15.00 | 21.00 | 46% | * | * | * | * | * | * | * | * | * | |||
| R20 T25 | 20.00 | 25.00 | 58% | * | * | * | * | * | * | * | * | * | |||
| R20 T27 | 20.00 | 27.00 | 50% | * | * | * | * | * | * | * | * | * | |||
| R20 T28 | 20.00 | 28.00 | 46% | * | * | * | * | * | * | * | * | * | |||
| R20 T30 | 20.00 | 30.00 | 40% | * | * | * | * | * | * | * | * | * | |||
| R25 T34 | 25.00 | 34.00 | 49% | * | * | * | * | * | * | * | * | * | |||
