AISI 304L Round Stainless Steel Sheet Hole Perforted 0.4 - 6.0 Thickness
AISI 304 304L Round Hole Perforted Stainless Steel Sheet 0.4-6.0 Thickness Patterns Appeal
Product Introduction
Perforated sheet metal is used in agriculture, mining operations, aerospace technology, audio equipment, lighting, security applications, textile manufacture, heating, ventilation and air conditioning, sugar processing and many other industries.Perforated Stainless Sheet is a sheet product that has been punched with a wide variety of hole sizes and patterns providing an aesthetic appeal. Perforated Stainless Sheet offers savings in weight, passage of light, liquid, sound and air, while providing a decorative or ornamental effect. Perforated Stainless Sheets are very corrosive resistant and commonly used in interior and exterior design.
|
Product Name
|
Perforated SS sheet
|
|
Grade
|
300 Series/400 series /200 series
|
|
Standard
|
JIS, AiSi, ASTM, GB, DIN
|
|
Length
|
1000m 2000mm 6000mm or customized
|
|
Width
|
1000mm 1220mm 2000mm or customized
|
|
Place of Origin
|
China
|
|
Model Number
|
304 304l 316 316l 309 310s 410 430
|
|
Type
|
Plate
|
|
Application
|
Construction /Building /Industry or etc
|
|
Certification
|
SGS/BV/ISO
|
|
Tolerance
|
±5%
|
|
Processing Service
|
Bending, Welding, Decoiling, Punching, Cutting, or other customized
|
|
Product Name
|
perforated metal per price kg ss sheet stainless steel plate
|
|
Technique
|
hot rolled cold rolled perforated punch
|
|
Surface
|
BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D
|
|
Price Term
|
CIF CFR FOB EX-WORK
|
|
Payment term
|
30%T/T Advance + 70% Balance
|
|
MOQ
|
1 Ton
|
|
Packing
|
Standard Sea-worthy Packing
|
|
Sample
|
Available
|
|
Stock
|
Available
|
|
Delivery time
|
7-15 days
|
| Description | Hole Size (mm) |
Pitch (mm) |
Open Rate | Sheet Thickness | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.4 mm |
0.5 mm |
0.8 mm |
1.0 mm |
1.2 mm |
1.5 mm |
2.0 mm |
2.5 mm |
3.0 mm |
4.0 mm |
5.0 mm |
6.0 mm |
||||
| R0.8 T2 | 0.80 | 2.00 | 15% | * | * | * | |||||||||
| R1 T2 | 1.00 | 2.00 | 23% | * | * | * | * | ||||||||
| R1.2 T2.25 | 1.20 | 2.25 | 26% | * | * | * | |||||||||
| R1.2 T2.5 | 1.20 | 2.50 | 21% | * | * | * | |||||||||
| R1.5 T2.75 | 1.50 | 2.75 | 27% | * | * | * | * | ||||||||
| R1.5 T3 | 1.50 | 3.00 | 23% | * | * | * | * | ||||||||
| R1.8 T3.5 | 1.80 | 3.50 | 24% | * | * | * | * | * | |||||||
| R2 T3 | 2.00 | 3.00 | 40% | * | * | * | |||||||||
| R2 T3.5 | 2.00 | 3.50 | 30% | * | * | * | * | ||||||||
| R2 T4 | 2.00 | 4.00 | 23% | * | * | * | * | * | |||||||
| R2.5 T3.5 | 2.50 | 3.50 | 46% | * | * | * | * | * | * | ||||||
| R2.5 T4 | 2.50 | 4.00 | 35% | * | * | * | * | * | * | ||||||
| R2.5 T4.5 | 2.50 | 4.50 | 28% | * | * | * | * | * | * | ||||||
| R2.5 T5 | 2.50 | 5.00 | 23% | * | * | * | * | * | * | ||||||
| R3 T5 | 3.00 | 5.00 | 33% | * | * | * | * | * | * | * | |||||
| R3 T6 | 3.00 | 6.00 | 23% | * | * | * | * | * | * | * | |||||
| R3.5 T5 | 3.50 | 5.00 | 44% | * | * | * | * | * | |||||||
| R4 T5 | 4.00 | 5.00 | 58% | * | * | * | |||||||||
| R4 T6 | 4.00 | 6.00 | 40% | * | * | * | * | * | * | ||||||
| R4 T8 | 4.00 | 8.00 | 23% | * | * | * | * | * | * | * | * | ||||
| R5 T7 | 5.00 | 7.00 | 46% | * | * | * | * | * | * | ||||||
| R5 T8 | 5.00 | 8.00 | 35% | * | * | * | * | * | * | * | * | ||||
| R5 T10 | 5.00 | 10.00 | 23% | * | * | * | * | * | * | * | * | * | |||
| R5 T2.5 | 5.00 | 25.00 | 4% | * | * | * | * | * | * | * | * | * | |||
| R6 T8.5 | 6.00 | 8.50 | 45% | * | * | * | * | * | * | * | |||||
| R6 T9 | 6.00 | 9.00 | 40% | * | * | * | * | * | * | * | * | ||||
| R6 T10 | 6.00 | 10.00 | 33% | * | * | * | * | * | * | * | * | * | * | ||
| R7 T10 | 7.00 | 10.00 | 44% | * | * | * | * | * | * | * | * | ||||
| R8 T8 | 8.00 | 11.00 | 48% | * | * | * | * | * | * | * | * | ||||
| R8 T8 | 8.00 | 12.00 | 40% | * | * | * | * | * | * | * | * | * | |||
| R8 T8 | 8.00 | 15.00 | 26% | * | * | * | * | * | * | * | * | * | |||
| R10 T13 | 10.00 | 13.00 | 54% | * | * | * | * | * | * | * | * | ||||
| R10 T14 | 10.00 | 14.00 | 46% | * | * | * | * | * | * | * | * | ||||
| R10 T15 | 10.00 | 15.00 | 40% | * | * | * | * | * | * | * | * | * | |||
| R10 T18 | 10.00 | 18.00 | 28% | * | * | * | * | * | * | * | * | * | |||
| R12 T16 | 12.00 | 16.00 | 51% | * | * | * | * | * | * | * | * | ||||
| R12 T17 | 12.00 | 17.00 | 45% | * | * | * | * | * | * | * | * | * | |||
| R15 T20 | 15.00 | 20.00 | 51% | * | * | * | * | * | * | * | * | * | |||
| R15 T21 | 15.00 | 21.00 | 46% | * | * | * | * | * | * | * | * | * | |||
| R20 T25 | 20.00 | 25.00 | 58% | * | * | * | * | * | * | * | * | * | |||
| R20 T27 | 20.00 | 27.00 | 50% | * | * | * | * | * | * | * | * | * | |||
| R20 T28 | 20.00 | 28.00 | 46% | * | * | * | * | * | * | * | * | * | |||
| R20 T30 | 20.00 | 30.00 | 40% | * | * | * | * | * | * | * | * | * | |||
| R25 T34 | 25.00 | 34.00 | 49% | * | * | * | * | * | * | * | * | * | |||
Product Show
Hot Patterns
Package
Shipping
F&Q
Q: ARE YOU FACTORY OR TRADER?
A: Lichuang Special Steel is a cold rolling manufacturer of magnetic stainless steel coil since 2009. We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.
Q: WHICH MATERIAL/PRODUCTS YOU CAN PROVIDE?
A: Stainless Steel Coils / Strips, Stainless Steel Sheets / Plates, Stainless Steel Circles / Discs, Decorative Stainless Steel Sheets.
Q: HOW TO GET A SAMPLE?
A: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.
Q: HOW TO VISIT YOUR FACTORY?
A: Most of the main cities have flights to Wuxi; you can take flight to Wuxi Shuofang International Airport.
If you come from Shanghai, it will take 2 hours by flight (every day 5 flights).
If you come from Hongkong, it will take 1 hour by flight (every day 1 flight around noon time).
