Triple Play SS316L 5um Composite Sintered Mesh Filter Plate Used In Pharmaceutical
Introduction of Composite Sintered Mesh Filter Plate
Several layers of plain or twilled woven wirand perforated metal(standard material SS304)are sintered together to make this special type of material.It enjoys the advantages of superior backwash,low pressure drop.It can be used in water treatment,beverage,food,metallurgy,chemical and pharmaceutical industries.Especially suitable for continuous and automatic operation process.It can not be compared with any kind of filter material.This sintered mesh material is easy to form processing and welding,it can be processed into various forms of filter elements such as circular,cylindrical,cone,corrugated.
Sintered filter element is a new type of filter material made of multi-layer metal sintered mesh, using multi-layer stainless steel mesh after special laminated pressing and vacuum sintering with high strength and overall steel.The mesh of each layer is interleaved to form a uniform and ideal filtration structure.
Our sintered mesh has been used in many industries such as aerospace,aviation,petroleum,chemical,metallurgy, machining,pharmaceutical,food,synthetic fiber,film,environment alprotection industries in respect of filtration and purification,gas-solid,liquid-solid,and gas-liquid separation,cooling,gas distribution,fluidization bed, gas sampling collection,shock reducing,sound attenuation,inflaming retarding.
Features
1.High temperature resistance.
2.High corrosion resistance.
3.Easy to backwash,reusable.
4.High precision.
5.High strength.
Scope of Use
Specifications
| Standard material | SUS316L,SUS304 |
| Available size | less than or equal 1200x1000mm |
| Filtration ration | 1-300um |
| Special sizes | customized |
| type | nominal precision(um) | absolute accuracy(um) |
air permeability (L/min ·cm2·pa) |
bubble point pressure(pa) |
| AI1 | 6-7 | 5300-6000 | ||
| AI2 | 2 | 8-9 | (1-6)×10-4 | 4300-5000 |
| AI5 | 11-13 | (6-10)×10-4 | 3000-3700 | |
| AI10 | 10 | 16-18 | (6-10)×10-4 | 2700-3300 |
| AI15 | 15 | 24-26 | (1-6)×10-3 | 2000-2600 |
| AI20 | 20 | 28-32 | (1-6)×10-3 | 1800-2300 |
| AI25 | 25 | 34-36 | (6-10)×10-3 | 1400-1900 |
| AI30 | 30 | 40-45 | (6-10)×10-3 | 1200-1700 |
| AI40 | 40 | 50-55 | (1-6)×10-2 | 1000-1500 |
| AI50 | 50 | 71-80 | (1-6)×10-2 | 900-1200 |
| AI70 | 70 | 80-95 | (6-10)×10-2 | 700-1100 |
| AI100 | 100 | 110-120 | ≥5×10-2 | 650-1000 |
Related Photos
The Reasons for Choosing Us
1.Filtration Specialists with 10 years’experience.
2.OEM Service for you and satisfy different markets demand.
3.Widely used in aviation, railway, power plant, coal mining, construction mining, etc.
4.Samples for 1 pcs and small order 5pcs are allowed.
5.Professional technical data systems guaranteed the correctness of filter.
Our Team
Certification
Packing
Transportation
FAQ
Q:Classification of sintered cartridge
A:First, according to the material, there are metal sintered cartridge and non-metal sintered cartridge. Metal sintered cartridge is mainly stainless steel series as the main material.There are also titanium rod sintered cartridges and monel sintered cartridges made of special metals. Non-metallic sintered cartridge has activated carbon as the material,carbon sintered cartridge; powder sintered cartridge and copper powder sintered cartridge made of metal powder; pe sintered cartridge made of polymer.
Second, according to the function, there are surface filtration sintered cartridge and depth filtration sintered cartridge. Like sintered mesh cartridge is surface filtration sintered cartridge. The general surface filtration type is the sintered cartridge with sintered mesh as the material, because the sintered mesh is the surface filtration. And like powder sintered, the sintered cartridge with fibers, particles and granules as materials such as sintered felt are depth filtration sintered cartridges. For example, copper powder sintered cartridge, activated carbon sintered cartridge, sintered felt cartridge, etc.
