Dia 3-6mm Aperture Industrial Basket Strainer Easy To Clean
Industrial Basket Strainer , Easy To Make , Easy To Install And Clean
Introduction
Basket filters are mainly composed of takeovers, main pipes, and filter baskets. It is composed of flange, flange cover and fasteners. When the fluid enters the filter basket through the main pipe, the solid impurity particles are blocked in the filter basket. When it needs to be cleaned, it can be rotated to open, and then reloaded after cleaning.
Feature
1. Standard stainless steel filter, the aperture is Φ3～6, and the number of apertures can be selected
2. Optional pressure gauge connection, cover the convex surface with threaded holes to install the pressure gauge
3. The flow area is large, so the pressure loss is small
parameter
| Number of holes | Wire diameter mm | interceptable particle sizeum | Aperture area(%) |
| 10 | 0.508 | 2032 | 36 |
| 12 | 0.475 | 1660 | 39 |
| 14 | 0.376 | 1438 | 37 |
| 16 | 0.315 | 1273 | 35 |
| 18 | 0.315 | 1096 | 39 |
| 20 | 0.273 | 955 | 33 |
| 22 | 0.234 | 882 | 31 |
| 24 | 0.234 | 785 | 44 |
| 26 | 0.234 | 743 | 41 |
| 28 | 0.234 | 673 | 44 |
| 30 | 0.234 | 614 | 47 |
| 32 | 0.234 | 560 | 50 |
| 36 | 0.234 | 472 | 54 |
| 38 | 0.234 | 455 | 54 |
| 40 | 0.193 | 442 | 51 |
| 50 | 0.152 | 356 | 50 |
| 60 | 0.122 | 301 | 49 |
| 80 | 0.102 | 216 | 53 |
| 100 | 0.081 | 173 | 54 |
| 120 | 0.081 | 131 | 62 |
| 150 | 0.065 | 104 | 31 |
| 200 | 0.050 | 74 | 33 |
| 300 | 0.035 | 44 | 30 |
photos
Our factory Strength for Stainless steel filter element
1: Filtration Specialists with 10 years ‘ experience.
2: OEM Service for you and satisfy different markets demand.
3: Widely used in Aviation , Railway, Power plant, Coal mining, Construction mining etc
4: Samples for 1 pcs and small order 5pcs are allowed.
5: Professional technical data systems guaranteed the correctness of filter.
