40um To 2000um Metal Cartridge Filter Industrial Barrel Filter
Industrial Basket Strainer , Alias Cartridge Filter , Barrel Filter
Introduction
It is mainly composed of connecting pipe, main pipe, filter basket, flange, flange cover and fasteners. When the liquid enters the filter basket through the main pipe, the solid impurity particles are blocked in the filter basket, and the clean fluid passes through the filter basket and is discharged from the filter outlet. When cleaning is required, unscrew the screw plug at the bottom of the main pipe, drain the fluid, remove the flange cover, and re-install it after cleaning. Therefore, it is extremely convenient to use and maintain
parameter
| Number of holes | Wire diameter mm | interceptable particle size um | Aperture area(%) |
| 10 | 0.508 | 2032 | 36 |
| 12 | 0.475 | 1660 | 39 |
| 14 | 0.376 | 1438 | 37 |
| 16 | 0.315 | 1273 | 35 |
| 18 | 0.315 | 1096 | 39 |
| 20 | 0.273 | 955 | 33 |
| 22 | 0.234 | 882 | 31 |
| 24 | 0.234 | 785 | 44 |
| 26 | 0.234 | 743 | 41 |
| 28 | 0.234 | 673 | 44 |
| 30 | 0.234 | 614 | 47 |
| 32 | 0.234 | 560 | 50 |
| 36 | 0.234 | 472 | 54 |
| 38 | 0.234 | 455 | 54 |
| 40 | 0.193 | 442 | 51 |
| 50 | 0.152 | 356 | 50 |
| 60 | 0.122 | 301 | 49 |
| 80 | 0.102 | 216 | 53 |
| 100 | 0.081 | 173 | 54 |
| 120 | 0.081 | 131 | 62 |
| 150 | 0.065 | 104 | 31 |
| 200 | 0.050 | 74 | 33 |
| 300 | 0.035 | 44 | 30 |
use industry
Certificate
photos
Our factory Strength for Stainless steel filter element
1: Filtration Specialists with 10 years ‘ experience.
2: OEM Service for you and satisfy different markets demand.
3: Widely used in Aviation , Railway, Power plant, Coal mining, Construction mining etc
4: Samples for 1 pcs and small order 5pcs are allowed.
5: Professional technical data systems guaranteed the correctness of filter.
transportation
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
