Illustration 1 g03836011
Front view
Table 1
Specifiion for the 282-8422 Exhaust Manifold Gp
Item Qty Part Specifiion Description
1 4 3J-5389 Plug Before assembly, apply Never-Seez Marine Grade to the threads.
Torque to 20 5 N m (177.0 44.3 lb in).
Illustration 2 g03836013
Top view
Table 2
Item Qty Part Specifiion Description
2 32 5P-3345 Bolt Before assembly, apply Never-Seez Marine Grade to the threads and to the bearing surfaces..
Use the following procedure in order to tighten the bolts :
1. Opposite bolts of each exhaust manifold are snug diagonally in order to seat the exhaust seal uniformly.
2. Torque the bolts to 55 5 N m (41 4 lb ft).
3 44 5p-3875 Bolt Before assembly, apply Never-Seez Marine Grade to the threads and to the bearing surfaces..
Torque the bolts to 50 5 N m (37 4 lb ft).
4 4 5p-3961 Bolt Before assembly, apply Never-Seez Marine Grade to the threads and to the bearing surfaces..
Torque the bolts to 50 5 N m (37 4 lb ft).
Illustration 3 g03836014
Right side view
Table 3
Item Qty Part Specifiion Description
5 8 5P-3345 Bolt Before assembly, apply Never-Seez Marine Grade to the threads and to the bearing surfaces..
Torque to 55 5 N m (41 4 lb ft).
