52x52mm AC120V Downlight AC LED Module With Smd2835 Aluminum PCBA
52x52mm AC120V Downlight AC LED Module With Smd2835 Aluminum PCBA
52x52mm DOB AC120V Aluminum With Smd2835 PCBA Led Module Pcb For Downlight
PCB SIZE : 52*52*1.6MMSpecial FeaturesSpecial FeaturesSpecial FeaturesSpecial FeaturesSpecial Features
LE52-DOB-8W is a complete ready to light ceiling lamp module, broad lens angle enables even light output.
CE certificated shorten the product time to market.
Support buletooth control with APP to adjust the brightness and color, no need additional hub.
Specification
|
Material |
Samsung 2835 LED |
|
Light Color |
Tunable Color from 2700K to 6000K |
|
CRI |
80/90 |
|
Light Output |
2000lm @5000K Ra80 20W |
|
HiPot |
1.5KV AC |
|
Surge Protection |
2.5KV Ring Wave |
|
Certification |
CE,CCC |
|
Features |
APP Dimming and Color Changing, Non Flicker |
|
Power |
120V 60Hz 8W |
|
Power Factor |
0.95 |
Product details
|
Model No. |
52x52mm AC120V 8W 17763 |
Power |
8W |
|
Input Voltage |
AC 100-130V 60Hz |
Input current |
0.082A |
|
Luminous Efficiency |
103 lm/W |
Color rendering index |
Ra 80 |
|
Anti-Surge Class |
1.0KV |
Thermal Conductivity |
1.0W/m.K |
|
Pcb Size |
D52mm*1.6mm |
Emitting Color |
White color |
|
Insulation Class |
ACW>1.5KV |
Operating Temperature |
-20~45°C |
Product details
