12mm Dual Wall Heat Shrink Tube ASTM D2671 RoHS Heavy Wall
12mm Black Heavy Wall Adhesive Lined Heat Shrinkable Tubing
• Adhesive-lined heavy wall heat shrinkable tube is produced by high quality polyolefin and hot melt adhesive through doublelayer co-extrusion process. The outer layer of this tube has high
physical and chemical properties, and good contraction, and so on.
• Anti-UV light, excellent waterproof, moisture-proof, and sealing and insulating performance.
• Minimum shrink temperature: 70°C
• Minimum fully recovery temperature: 125°C
• Operating temperature: —45°C〜110°C
• Shrink ratio: 3: 1
• Environmental standards: RoHS
• Color: Black
Technical Date
| Property | Test Method | Stantard |
| Tensile Strength(MPa) | ASTM D2671 | N14 |
| Elongation!%) | ASTM D2671 | ^400 |
| Tensile Strength After Aging (MPa) | UL224158XX168hrs | 212 |
| Elongation at Break After Agingl%) | UL224158TX168hrs | ^300 |
| Longitudinal Shrink Ratio(%) | UI224 | |
| Dielectric strength(kV/mm) | IEC243 | 320 |
| Volume ResistivitylQ cm) | IEC93 | R x10" |
| Water absorption!%) | ASTM D570 | <0.5 |
| Operation Temperature | -45°C〜11(TC | |
| ShrinkTemperature | 70°C 〜125°C | |
| Environmental Standard | ROHS Compliant | |
| Standard Color | Black(other colors are available upon request) | |
| Material: (1)EVA；⑵hot-melt adhesive | ||
Adhesive Property
| Property | Test Method | Stantard I |
| Water Absorption | ASTM D570 | WO.2% |
| Sofening Point | ASTM E28 | 95°C |
| Peel Strength(PE) | ASTM D 1000 | 120N/25mm |
| Peel Strength(AL) | ASTM D 1000 | 80N/25mm |
FAQ
Professional Production Quality is Reliable
Q1 . Which certifications or test reports do you have?
A : We have UL,ROHS and REACH.
Q2 . How to ship my order? Is it safe?
A : For small package, we will send it by Express,such as Fedex, UPS,TNT, DHL and so on.
For big packages, we will send them by Air or By sea or by Train. We will use good packing and ensure the safety. We will be responsible to any product damage caused on delivery.”
Q3 . What about your delivery time?
A : We have a lot of products in stock. We can send the stock products in 3 work days.
If without stock,or stock is not enough, we will check the delivery time with you.” (Usually is 3-7days).
Q4 . Can you provide samples? Are the samples free?
A : Yes. We can provide samples.
Usually for our standard products with stock, we can supply samples free for testing.
Q5 . Could I put my own logo on it?
A : Sure, of course, we are a professional manufacture and have over 10 years OEM experience.
