Semi Conductive Dual Wall Heat Shrink Tube 45mm 17mm Black

Price Negotiable

Price: Can discussible

MOQ: 1m

Delivery Time: 1-9days

Brand: Long

Product Description

Black Heat Shrink Semi-Conductive Tube Shrink Temperature Start At 90°C And Fully Recovered At 130°C

・ Manufactured from cross linked semi-conductive polyolefin

・ Shrink temperature: start at 90°C, and fully recovered at 130°C

・ Color: black

Selection Table

Product No.	Inner Diameter/mm		After Recovered Wall Thickness (±0.2)/mm	Standard Cut Length/mm	Standard Continuous Length (m/roll)
Product No.	As 腳 led	After Recovered (Max)	After Recovered Wall Thickness (±0.2)/mm	Standard Cut Length/mm	Standard Continuous Length (m/roll)
WRSBG-45/17	45	17	2.3	400-1200	25
WRSBG-50/17	50	17	2.3	400-1200	25
WRSBG-50/19	50	19	2.3	400-1200	25
WRSBG-55/19	55	19	2.3	400-1200	25
WRSBG-55/23	55	23	2.3	400-1200	25
WRSBG-60/23	60	23	2.3	400-1200	25
WRSBG-60/25	60	25	2.3	400-1200	25
WRSBG-65/25	65	25	2.3	400-1200	25
WRSBG-75/29	75	29	2.8	400-1200	25
WRSBG-80/29	80	29	2.8	400-1200	25
WRSBG-85/29	85	29	2.8	400-1200	15
WRSBG-100/29	100	29	2.8	400-1200	15
WRSBG-100/35	100	35	2.8	400-1200	15
WRSBG-120/35	120	35	2.8	400-1200	15
Technical Data
Property		Test Method		Standard Value
Tensile Strength		ASTM-D-638		Ml3MPa
Elongation at Break		ASTM-D-638		M300%
Tensile Strength after Aging		ASTM-D-638	^10.5MPa(130r,168hrs)
Elongation at Break after Aging		ASTM-D-638	N240% (130r,168hrs)
Volume Resistivity		IEC 60093		ml x 105Q • cm
Longitudinal Shrinkage		ASTM-D-2671		W10%
Eccentricity		ASTM-D-2671		<30%
WaterAbsorption		ISO 62		W0.5%
