Glass Bottle Printing Machine 30000bph Date Coding Machine 180kw
30000bph Capacity High Precision Date Coding Device For Glass Bottles
Characters:
• Use air cooling system, with long time continuous working ability.
• The laser power is 30W which can print Chinese, English and patterns clearly, and can meet the requirements of printing all similar products by only one machine.
• High efficiency laser, high-speed galvanometer scanning system and control software, with high speed, good light output mode, stable performance and high system configuration.
• Fully enclosed optical path system can better protect optical devices from external environment.
• The stable and portable lifting mechanism of the main beam can adapt to different positions and shapes of product in different lines.
• Using professional optical fiber probe, no gap printing and no missing printing.
• Equipped with a smoke extraction device, which can quickly exhaust the smoke and dust generated by code printing and protect the environment of the printing area (optional).
• Chinese and English operation interface, Standard keyboard, mouse operation, equipment with standard expansion interface, convenient hardware expansion.
The details of product:
Technical parameters:
| Laser type | Metal tube carbon dioxide laser |
| Laser power | 30W |
| Laser head | Length: 750mm Width: 160mm Height: 180mm |
| Whole machine Power | 800W |
| Print line speed | ≤150m/min |
| Number of flight mark lines | 10X 10 |
| Minimum line width | 0.15mm |
| Minimum character | 0.40mm |
| Repeating accuracy | ±0.01mm |
| Laser wave length | 10.6µm |
| Divergence angle miliradian | 7.5mrad |
| Fastest printing line speed | 7000mm/s |
| Number of characters printed per second | 1200bps |
| Focal length | 120mm |
| Rows | Any rows |
| Character height | 0.5~100mm |
| Print information | Line height 0.5-100mm,Max 300mm |
| Print range | 90*300mm |
| Cooling way | Air cooling |
| Environment literature | 5-45℃ |
| Environment humidity | 90% non-condensing |
| Print content | English letter,Arabic numerals and patterns |
| Optimal print interval | ≥1mm |
| Power Supply | Ac 110V-220V/50HZ,5A |
| Humidity | 10%-90% |
| Communication interface | USB,RS232/485,Ethernet |
| Protection degree | IP54 |
| Detection settings | Photoelectric sensor,PNP/12V |
| Size and weight: |
Laser head 850*170*195mm 25KG Laser bracket 1500*600*580mm 22KG Controller 275*210*30mm 2KG |
Service:
1. we can send you the video of the running machine.
2. you are always welcome to come to visit our factory, and you may see the operation of the machines here . We will make the arrangement to pick you up when you come .
3. If we get the permission of the customer who has brought the machines from us ,we can tell you their contact information, you can go to visit their factory.
Customized service
1. we can design the machines according your requirements(material ,power,filling type,the kinds of the bottles, and so on).
2. at the same time we will give you our professional suggestion .
After-sales service
1. we will provide the bill of load on time to make sure you can get the machine quickly
2. when you finish the Preparation conditions ,our engineer will go to your factory for the installation, testing and also training .
3. we provide one year warranty with spare parts free.
