CNC Mono Wire Saw Machine 4-Axis Linkage 2500x3000x1500mm for Marble Granite Arc Slab Column Roman Pillar Stone Cutting Processing
Advanced CNC column granite marble profile cutting diamond wire saw machine designed for precision stone cutting applications. This 4-axis linkage system handles processing sizes up to 2500x3000x1500mm for complex shape cutting.
The CNC-2500S/3000S mono wire cutting machine (rope saw) is engineered for cutting column slabs, semi-circular slabs, English letters, and other diversified complex special shapes. Compatible materials include marble, granite, and natural stone.
- Heavy load bearing structure with four orbits on each upright column
- Roller-adjusted balance system for minimal friction and higher precision
- Synchronized lifting system with lead screw and double nuts for accuracy
- CNC-controlled guide wheel with rotating angle control via reducer
- Worktable operation through lead screw and railway system
- Automatic wire breakage alarm system
- 1600mm aluminum wheel diameter with oil pump controlled rope tension
| Parameter | Unit | CNC-2500S | CNC-3000S | CNC-2500SA | CNC-3000SA |
|---|---|---|---|---|---|
| Max processing size (L*W*H) | mm | 2500x3000x1500 | 3000x3000x1500 | 2500x3000x1500 | 3000x3000x1500 |
| Dimension of worktable | mm | 1400x2000 | 1600x2000 | 1400x2000 | 1600x2000 |
| Main motor | Kw | 11 | 11 | 11 | 11 |
| Table rotation control mode | / | Ordinary motor drive | Ordinary motor drive | Servo motor drive | Servo motor drive |
| Outline dimension (L*W*H) | mm | 7800x6800x4100 | 8800x6800x4100 | 7800x6800x4100 | 8800x6800x4100 |
| Gross weight | Kg | 7750 | 8250 | 7750 | 8250 |
| Table bearing weight | t | 15 | 15 | 15 | 15 |
Fujian Xianda Machinery Co. Ltd, established in 1985, specializes in developing and producing column making machines, wire saw stone cutting machines, block trimming machines, bridge saw cutting machines, and profiling stone cutting machines. With ISO9001 certification and CE compliance, we maintain a commitment to advanced technology and high quality.
- Top 10 stone cutting machine manufacturer with ISO & CE certification since 1985
- 70% China market share in special shape stone cutting machines
- Comprehensive quality control with experienced QC team
- Testing video provided before shipping upon customer request
- One-year warranty on all machines
- 24-hour response time for customer inquiries
- Technical support available at any time
- Free replacement for confirmed quality-related failures
