Manufacturer Supplier High Strength Gr9 Titanium Alloy Tube 3000mm Length For Industry
Supplier High Strength gr9 TitaniumTube Ti3Al2.5v Tube Titanium Tube for industry
Grade : Gr1,Gr2,Gr3,Gr5,Gr7,Gr9,Gr11,Gr12,Gr16,Gr17,Gr23
Standard: ASTM B337,ASTM B338,ASTM B861
Specifications :
1.Dimensions
A).Seamless titanium tube range:
OD:2.0mm-219mm
WT:0.3mm-120mm
Length: <18000mm
Material:Gr1, Gr2, Gr3, Gr4 Gr5, Gr7, Gr9, Gr11, Gr12, Gr16,Gr17, Gr23
B).Welded titanium tube range:
OD:6mm-219mm
WT:0.5mm-10mm
Length:<18000mm
Material: Gr1,Gr2,Gr3,Gr5,Gr9
| Name | Size(MM) | Grade |
| Seamless Tubes | OD(3~114)×(0.2~6.0)×L | Gr1,Gr2,Gr3,Gr4,Gr5, Gr7,Gr11,Gr23etc |
| Welded Tubes | OD (10~40)×(0.5~5.0)×L | |
| Extruded Tubes | OD (25~210)×(6.0~30)×L |
Titanium Seamless Tube
Specifications
| Product | ATitanium Pipe seamless pipe |
| Size |
Cold-rolled: OD: 8.0mm-114.0mm (0.32"-4.49"), WT: 0.5mm-7.5mm (0.02"-0.30"), Length: 4000mm (157.5") max (OD.: 8.0mm-15.0mm, 0.32"-0.59"), 12000mm (472.4") max (OD. over 15mm, 0.59")factory price 1.5mm 1.6mm 40mm titanium seamless pipe tube Extruded: OD: 25mm-210mm (0.98"-8.27"), WT: 4mm-30mm (0.157"-1.18"), Length: 1000mm-10000mm (39.4"-393.7") |
| Material | Gr.1, Gr.2, Gr.3, Gr.7, Gr.9, Gr.12, etc. |
| Standard | ASTM B 338, ASTM B 337, ASTM B 861 |
| Shape | Round |
Specific dimension for cold-rilled tubes & pipes:
| OD(mm) | 8.0-10.0 | 10.0-15.0 | 15.0-20.0 | 20.0-25.0 | 25.0-30.0 | 30.0-35.0 |
| WT(mm) | 0.15-2.0 | 0.2-2.0 | 0.4-2.7 | 0.45-3.2 | 0.45-3.3 | 0.45-3.4 |
| OD(mm) | 35.0-40.0 | 41.0-45.0 | 46.0-50.0 | 51.0-55.0 | 56.0-60.0 | 61.0-65.0 |
| WT(mm) | 0.5-3.5 | 0.6-3.8 | 0.6-3.8 | 0.6-4.4 | 0.8-4.6 | 0.9-4.7 |
| OD(mm) | 66.0-70.0> | 71.0-75.0> | 76.0-95.0 | 96.0-114.0 | ||
| WT(mm) | 1.0-4.9 | 1.2-6.0> | 1.2-7.1 | 1.3-7.5 |
Supply state: Annealing state (M)
Packing: according to customer's requirement. (Woven bag, wooden case)
Quality inspection: stain inspection, entrust third party inspection
Advantages of gr9 titanium tube:
1. Excellent high and low temperature performance. At present, the working temperature of new heat - resistant titanium alloy can reach 550-600℃ .Low temperature titanium alloy can maintain good toughness at -253.
2. Strong corrosion resistance The surface will quickly form thin and dense titanium oxide film, so in the atmosphere, seawater, nitric acid and sulfuric acid and other oxidizing medium and strong alkali, its corrosion resistance is better than most stainless steel
Payment Terms :
We accept the following payment terms:
1. Paypal Payment
2. T/T: Telegraphic Transfer(wire transfer), 30% deposit,balance before shipment.
3. L/C At Sight: Letter of Credit. (For order over US$30,000)
Baoji City Changsheng Titanium Co., Ltd. is located in Baoji City, which is called "Titanium City". We are a high-tech enterprise which mainly operates metallic titanium and titanium alloy materials. Our factory was established in 2001. We are a professional manufacturer for processing and producing metallic titanium, as well as titanium alloy materials. At present, we have a complete production line of metallic titanium and titanium alloy materials. There are six engineers, twelve advanced artificers, and forty production artificers in our company. Our factory is known as advanced processing technology, strong technical force, excellent quality, prompt delivery, and high credibility. Our factory is located in Baoji, the largest Non-ferrous base of China's Non-Ferrous Metals Processing Plant. The factory is located near Xian-Baoji Highway, possessed very convenient transport. We own the complete production line of bar materials: forging, rolling, grinding, and machining and are able to achieve large-scale production of different thickness, different scales, varieties, and different specifications for a variety of bars, forged products like titanium ring, flange and disc etc. We also possess a production line for titanium tubes, sheets... Our company is strictly in accordance with ISO9001:2000 quality system certification. High-effect management system will provide you best quality goods and earlier delivery time.
