supplier AMS 4911 L Titanium 6AL 4V gr5 Titanium Alloy Sheet For Aerospace
Supplier AMS 4911 L Titanium Plate GR5 Titanium Alloy Sheet For Aerospace
Titanium alloy,sheet,strip,and plate 6Al-4V annealed
This specification covers a titanium alloy in the form of sheet,strip,and plate.
Titanium Grade 5 (Ti6Al-4V) is the most commonly used alloy. Ti6Al4V is significantly stronger than other commercially pure titanium whilst still retaining the same stiffness and thermal properties (excluding thermal conductivity). Titanium Grade 5 extensively used in Aerospace, Medical, Marine and Chemical Processing.
Processing technique:titanium sponge compacting electrode melting titanium ingots forging slab hot rolling hot rolled sheets
Chemical Composition and tensile properties in Aerospace AMS 4911 L:
| Element | min | max |
| Aluminum | 5.5 | 6.75 |
| Vanadium | 3.5 | 4.5 |
| Iron | -- | 0.3 |
| Oxygen | -- | 0.2 |
| Carbon | -- | 0.08 |
| Nitrogen | -- | 0.05 |
| Hydrogen | -- | 0.015 |
| Yttrium | -- | 0.005 |
| Other elements,each | -- | 0.1 |
| Other elements,total | -- | 0.4 |
| Titanium | remainder | remainder |
Minimum tensile properties,SI UNITS
|
Nominal Thickness, Millimeters |
Tensile Strength Mpa |
Yield Strength At 0.2% Offset Mpa |
Elongation in 50.8mm or 4D % |
| Up to 0.20,excel | 920 | 866 | -- |
| 0.20 to 0.63, excel | 920 | 866 | 6 |
| 0.63 to 1.60, excel | 920 | 866 | 8 |
| 1.60 to 4.76, excel | 920 | 866 | 10 |
| 4.76 to 101.6, excel | 893 | 823 | 10 |
Hot tag:titanium plate,titanium plate AMS 4911 L.titanium sheet price per kg
