20M Roofing Sheet Roll Forming Machine Cr12 CE Roof Panel Roll Former

Price Negotiable

Price: Negotiable

MOQ: 1 set

Delivery Time: 50 days

Brand: DLY

Product Description

20 years 20 m speed PPGI Roof Tile Making Machine With CE

1. Processing flow diagram of machine

Infeed has hardened roller bearing guides that ensures the material guides perfectly into the roll stations.
Front Rotary Cut allows the customer to cut back on wasted material.
14-30 Tool Stations help form the Profile Panel.
The encoder features a wheel that sits on top of the panel passing through the machine. The tension spring allows constant contact of the encoder with the coil for consistent and accurate lengths.
The hydraulic Post Shear is guided by 4 bearing shafts for burr free cutting of the panel. The post shear enables cuts of 100 mm long panels up to 18.3 m.

2. Roof Tile Making Machine specifications

Name	roof tile making machine
material	PPGI GI
feeding material thciness	0.5mm - 0.6mm
Applicable Industries	steel construction
Tile Type	metal roofing
Use	roof wall and fence
Solid Keyed Shafts	85mm
Voltage	380v / 480v / 220v
Bearing Shafts	4 Bearing Shafts
Warranty	14 months
Cutter material	GCr12 chromed and quenched for good hardness and using
Warranty of core components	14 months
Color	blue and yellow or custom request
After Warranty Service:	Video technical support, Online support, Spare parts
Hydraulic power	5.0kw
Roller material	45# steel with chroming
language	English / Chinese / according to customer's request

3. Component of roof tile making machine line

5. Options

CNC cut to length - We offer also a CNC Cut-to-length on top of rollformer with run out supports.
rollout safety - Rollout safety cages in lieu of quick change side cages.
stacker - Stack the finished parts on an stacker. Available in different lenghts with a capacity of up to 3500 kg
