China En12966 LED Passenger Information Displays P3 P8 P10 For Bus Station for sale

En12966 LED Passenger Information Displays P3 P8 P10 For Bus Station

Name: En12966 LED Passenger Information Displays P3 P8 P10 For Bus Station
Brand: Yaham Optoelectronics Co., Ltd.

Price Negotiable

Price: USD1696-4124/pieces

MOQ: 1

Delivery Time: 30

Brand: YAHAM

Product Description

En12966 LED Passenger Information Displays P3 P8 P10 For Bus Station

En12966 Traffic Vms Passenger Information Led Displays P3 P4 P6 P8 P10mm Full Color Variable Message Sign For Bus Stati

Product Description

The Yaham PID traffic system provides real-time bus arrival and departure information,
operational and commercial messages to passengers via the display units in passageways
at entrances, platforms and concourses of public traffic stations. It guide passengers through
the station, designate boarding locations and announce arrivals and departutes. These
passenger information display reinforce audio notifications while withstanding brake
dust, vandalism and hard weather at platforms, stations, airports.

Specifications

Item	P6	P8	P10	P12	P16
Pixel pitch	6mm	8mm	10mm	12mm	16mm
LED type	SMD 3 in 1	SMD 3 in 1	SMD 3 in 1	SMD 3 in 1	SMD 3 in 1
Pixel density	27777 pixels/m²	15625 pixels/m²	10000pixels/m²	6944pixels/m²	3906 pixels/m²
Pixel configuration	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Module dimension (Wx H)	192x192 mm	256×128 mm	320×160 mm	192x192 mm	256×128 mm
Module resolution (Wx H)	16×8	16x16	32x16	32×32	32×32
Screen weight	60kg/m²	60kg/m²	60kg/m²	60kg/m²	60kg/m²
Viewing angle	H140°/V140°	H140°/V140°	H140°/V140°	H140°/V140°	H140°/V140°
Best viewing distance	6m~50m	8m~80m	10m~100m	12m~100m	16m~100m
Brightness	5,000~8,000 nits	6,000~7,000 nits	5,000~7,000 nits	5,000~7,000 nits	5,000~7,000 nits
Gray scale	≥14bit	≥14bit	≥14bit	≥14bit	≥14bit
Colour	68.7 billion color	68.7 billion color	68.7 billion color	68.7 billion color	68.7 billion color
Color temperature	5,500k~8,000k	5,500k~8,000k	5,500k~8,000k	5,500k~8,000k	5,500k~8,000k
Refresh rate	≥1920Hz	≥1920Hz	≥1920Hz	≥1920Hz	≥1920Hz
Contrast ratio	≥4000:1	≥2000:1	≥2000:1	≥2000:1	≥2000:1
Power supply	100~240V	100~240V	100~240V	100~240V	100~240V
Storage temperature	-20°C~60°C	-20°C~60°C	-20°C~60°C	-20°C~60°C	-20°C~60°C
Operation temperature	-20°C~50°C	-20°C~50°C	-20°C~50°C	-20°C~50°C	-20°C~50°C
Operation humidity	5%~95%RH	5%~95%RH	5%~95%RH	5%~95%RH	5%~95%RH
Input signa	DVI/VGA, RGBHV,Composite Video signal, S-VIDEO, YPbPr(HDTV
Driving method	1/8 dynamic	1/4 dynamic	1/2 dynamic	1/2 dynamic	static
Max. Power consumption	600W/m²	600W/m²	600W/m²	600W/m²	600W/m²
Avg. Power consumption	240W/m²	180W/m²	180W/m²	180W/m²	180W/m²
