IP56 Solar warning LED Road Sign Board Illuminated energy saving

Price Negotiable
Price: $1200-2000 Square Meter/Square Meters
MOQ: 14 Square Meter/Square Meters
Delivery Time: 35-40 work days
Brand: YAHAM
Product Description

IP56 Solar Warning LED Road Sign Board Illuminated Energy Saving



Traffic solar led warning road sign board 65kg/m² lifespan >100000 hrs IP56



Variable message signs Application
Generally speaking, variable message sign is used to communicate in realtime with motorists. variable message sign must address current conditions on the roadway by being dynamic, accurate, timely and understandable. When there are multiple requests to post VMS messages simultaneously, messages will be prioritized in the following order .YAHAM traffic variable message led display is widely used in highway, city road, highway tunnel road, displaying the road situations info, Traffic command department dispatches information, weather information and so on.



1. DIP led encapsulation confirm high brightness and good heat dissipation,meet to any weather

2. Lower power consumption,only need 3.8V and 7.65W for single module,the average power consumption is only 100W/sq.m and 350W/sq.m for max power consumption for screen,that is to say, a panel of 960x960mm only need two power supply

3. Good waterproof IP65 anti-corrosion,antifogging,long life span>100000Hours

4. Brightness can be adjusted automatically according to different surrondings,can be set to open and close the screen on fixed automatically

5. Made with high quality Epistar leds keep high quality, low lighting decay, energy saving



Competitive Price
YAHAM believes to give competitive prices, it should push its own suppliers for competitive prices. YAHAM audit, bargain with its suppliers on behalf of you to reflect decreased prices.



Product Description
low power led display screen, above 50% energy-saving than traditional, but still keep high brightness up to 7500nits,and competitive price



Item YHT-VMS-D25
Pixel pitch 25mm
LED type 510 DIP
Pixel density 1600 pixels/m²
Module dimension 200×200 mm
Module resolution 8×8
Cabinet material 2mm aluminum Alloy
Cabinet dimension 1000×1000 mm
Brightness L3: EN12966 (Red: >3100nits, Green>3720nits,Blue>1240nits, Amber>7440nits,
Driving method Static
Brightness adjustment 32/256
Color coordinates C2: EN12966
Viewing angle H.30°, V.30°(B6:EN12966)
Contrast ratio R3: EN12966
Refresh rate >90+ Hz
Display control Asynchronous control system available
Signal transfer Cat 5 Network Cable, RS232,RS485 optional
Display capacity Text, image, graphics animations
Power supply 12-24v /220v
Max. Power consumption 200W/m²
Avg. Power consumption 70W/m²
Operation temperature -25~ 60°C
Storage temperature -40~ 80°C
Operating humidity 10%~ 90%
Store humidity 15%~ 95%
