Programmable P16 vMS lED display Board Traffic Control Information
Programmable P16 VMS LED Display Board Traffic Control Information
Traffic control sign en12966 ntcip programmable p16 module led vms display
Feature
Smart monitor
Yaham VMS can activate self-diagnosis and report health status, monitor can identify equipment health status, current message ID, current operating mode temperature, humidity, etc
Energy-efficient
Industry-leading dual-voltage technology, it can tremendously improve energy efficiency and maximumly lower light pollution.Technology
--Sleep mode:
YHT-VMS product,in the blank area, only a 10uA current will flow in each channel under sleep mode. A sample calculation for energy saving is showingas follows. YHT-VMS product will save around 800 times for every single IC driver than general VMS!
--Dual Voltage
Due to lighting chip difference inside, Red/Amber LED has lower threshold voltage to light up than Green/Blue LED. So, we applied dual voltage channel to drive two types of LEDs. Surplus energy is saved by this technology. Using separate voltage driving board to achieve energy-saving purpose:specific voltages are applied to different lamps.
| Item | YHT-VMS-OT10 | YHT-VMS-OT12 | YHT-VMS-OT16 |
| Pixel pitch | 10mm | 12mm | 16mm |
| LED type | 3 in1 SMD+lens | 3 in1 SMD+lens | 3 in1 SMD+lens |
| Pixel density | 10000 pixels/m² | 6944 pixels/m² | 3906 pixels/m² |
| Module dimension | 320×160 mm | 192×192 mm | 256×128 mm |
| Module resolution | 32×16 | 16×16 | 16×8 |
| Cabinet material | 2mm aluminum Alloy | ||
| Screen weight | 65kg/m² | ||
| Cabinet dimension | 960×960 mm | 960×960 mm | 1024×1024 mm |
| Brightness | L3,L3*:EN12966 (Red: >3100nits, Green>3720nits, Blue>1240nits, Amber>7440nits, White:>12400nits) | ||
| Brightness adjustment | 32/256 | ||
| Color coordinates | C2: EN12966 | C2: EN12966 | C2: EN12966 |
| Refresh rate | >90+ Hz | >90+ Hz | >90+ Hz |
| Display control | Asynchronous control system available | ||
| Display capacity | Text, image, graphics animations | ||
| Lifespan | >100000 hrs | >100000 hrs | >100000 hrs |
| Power supply | 12-24V DC/110-230V AC | ||
| Max. Power consumption | 400W/m² | 380W/m² | 250W/m² |
| Avg. Power consumption | 130W/m² | 120W/m² | 80W/m² |
| Operation temperature | -25~ +60°C | ||
| Storage temperature | -40~ +80°C | ||
| Store humidity | 15%~ 95% | 15%~ 95% | 15%~ 95% |
| Maintenance method | Rear service | Rear service | Rear service |
| EN12966 | compliance | compliance | compliance |
