SUS304 Stainless Steel Battery Test Equipment Combustion Jet 380V
SUS304 Stainless Steel Battery Combustion Jet Test Equipment By 380V
Product introduction:
The battery combustion jet test equipment is mainly used to test the flame resistance of the battery.
The principle is to place the battery on a flame resistant and high temperature resistant mesh screen (the mesh screen has 20 holes every 25.4mm, and the diameter of the steel wire is 0.43mm), and then light the burner below it (38.1mm above the top of the burner). At the same time, observe the battery combustion until the battery explodes or burns down, and time the combustion process.
Standards:
IEC60086-4:2000,UL1642:1995), UL2054:1997), UL1642 [13], GB8897.4-20026.3.2.9, GB312412014.
Technical Specifications:
1. Burner: inner diameter of pipe orifice is 0.375 inch (9.5 mm) and length is about 100 mm;
2. Bunsen burner can adjust the burning angle of 0-45-90 degrees and is equipped with corresponding angle indicator;
3. Flame application time: 0~99.9 seconds ± 0.1 seconds;
4. Flame height: 10~75 ± 2mm (adjustable);
5. Ignition device: automatic ignition;
6. Width of test cover: 610mm X depth 355mm, octagonal (use double-layer mesh holder to realize rapid replacement of aluminum mesh
7. Height of test cover: 305mm;
8. Test aluminum mesh diameter: 0.010 inch (0.25mm) 16 mesh × 16 mesh;
9. Surface diameter of test round hole: 102mm.
Specifications:
| 1. Inner box size | 400x400x400mm (width x depth x height); |
| 2. Dimensions | 800x700x1310mm (width x depth x height); |
| 3. Temperature range | RT+10~200℃; |
| 4. Temperature display accuracy | 0.1℃; |
| 5. Temperature stability | ±1.0℃; |
| 6. Temperature uniformity | ±2℃; |
| 7. Heating time | (5±1)℃/min; |
| 8. Internal material | SUS304 stainless steel plate, thickness 1.2mm; |
| 9. External material | 1.5mm thick cold-rolled steel plate with paint treatment; |
| 10. Box door | a single door opens to the left, and an explosion-proof chain is installed on the side of the box door; |
| 11. Smoke exhaust pipe | diameter φ100mm, located at the back of the box |
| 12. Control method | PLC touch screen control; |
| 13. Temperature collection range | RT+10 ~ 1000℃; |
| 14. Temperature acquisition channel | 1 channel; |
| 15. Voltage acquisition range | 0-100V; |
| 16. Voltage acquisition channel | 1 channel; |
| 17. Maximum short-circuit current | 1000A; |
| 18. Current acquisition channel | 1 channel; |
| 19. The internal resistance of the device loop | 80±20mΩ; |
| 20. Pressure relief door size | 200x200mm; |
