Sus304 Altitude Test Chamber Environmental Simulation Antirust
Sus304 Altitude Test Chamber Environmental Simulation Antirust
The box body is processed and formed by numerical control machine tool. The shape is beautiful and generous, and the handle without reaction is used, so the operation is simple.
The inner liner of the box is made of imported advanced stainless steel (SUS304) mirror plate, and the outer liner is made of A3 steel plate sprayed with plastic, which increases the appearance texture and cleanliness.
The water refill tank is placed in the lower right part of the control box, and has automatic protection of water shortage, which is more convenient for the operator to replenish water.
Large observation window with light to keep the box bright, and the use of heating body embedded toughened glass, at any time clear observation box condition.
The humidification system pipe is separated from the control circuit board to avoid faults caused by water leakage in the humidification pipeline and improve safety.
Waterway system pipeline circuit system is easy to maintain and repair.
Ultra fine glass fiber thermal insulation cotton is used for box insulation to avoid unnecessary energy loss.
The left side of the box is equipped with a 50mm diameter test hole, which can be used for external test power line or signal line.
Features:
1. Temperature: -70 ~170ºC
2. Altitude: ground to 100,000 feet
3.External pressure type box body structure and stainless steel tank design, rational air circulation system and scientific layout of heating, refrigerating system.
4.Adopts international brand of imported parts for cooling system to improve operation reliability
5. High precision and stable performance with touch screen controller, friendly Man-Machine interface.
6. Multiple layers of safe device, easy for maintenance.
7. Viewing window and cable ports are available.
8. Vacuum pump sized for climb/dive rate required by application
|
Item
|
Specification
|
|
Internal material
|
#304 stainless steel, mirror finished
|
|
External material
|
Stainless steel with paint spray
|
|
Temperature range
|
-40~+100℃
|
|
Temperature fluctuation
|
±0.5℃
|
|
Temperature uniformity
|
±2℃
|
|
Cooling speed
|
1℃/min in average (without loading)
|
|
Heating speed
|
3℃/min in average (without loading)
|
|
Humidity
|
20 to 98% RH, without loading
(temperature from +20℃ to +85℃) |
|
Humidity fluctuation
|
±2.5%
|
|
Humidity uniformity
|
±3%
|
|
Controller
|
TATO PLC touch screen controller,
With RS232 and USB port, APP remote control function |
|
Vacuum range
|
Ordinary pressure ~ 1Kpa
|
|
Pressure fluctuation
|
±5%
|
|
Decompression time
|
≤10min
|
We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from. Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national authoritative third-party inspection agency
