Household LiFePO4 Lithium Battery Inverter 5000W LFP Solar Renewable
Price:
Negotiable
MOQ:
1unit
Delivery Time:
7-15 working days
Brand:
CLF
Product Description
All-In-One LiFePO4 Lithium Battery Household Home Solar Energy Storage System Inverter OEM ODM 5000W LFP Solar Renewable
All-in-One is composed of photovoltaic energy storage hybrid inverter, energy storage battery module, wireless communication module or display screen. Connected to solar panel, photovoltaic power generation and system can be formed. The main function is to convert direct current of photovoltaic and battery into alternating current and output power to load.
The system is equipped with EMS(energy management system) and BMS(battery management system) to realize data monitoring, early warning and control.
Specifications
| Model | HY- ()-15KWH- () | HY- ()-20KWH- () | HY- ()-25KWH- () | HY- ()-30KWH- () |
| Battery Voltage | 120-175.2V | 160-233.6V | 200-292V | 240-350.4V |
| Battery Rated Voltage | 153.6V | 204.8V | 256V | 307.2V |
| Battery Module Quantity |
3 | 4 | 5 | 6 |
| Battery Module Dimention |
640*400*685mm | 640*400*895mm | 640*400*1105mm | 640*400*1315mm |
| Cabinet Dimention | 640*400*1555mm | 640*400*1765mm | 640*400*1975mm | 640*400*2185mm |
| Battery Module Voltage Range | 40-58.4V | |||
| Battery Module Rated Voltage | 51.2V | |||
| Battery Module Power | 5.12kwh | |||
| Battery Module Dimension (L*W*H) |
640*400*210mm (with holder higher 55mm) |
|||
| Battery Module Weight | 46.9kg | |||
| With Holder Weight | 57.7kg | |||
| Max Charge/Discharge Current |
40A/80A | |||
| Battery Type | LiFePO4 | |||
| Communication Connecter |
CAN | |||
| Waterproof Level | IP20 | |||
| Operating Temperature | -15℃~55℃ | |||
| Noise | ＜30dB | |||
| Description | Each battery pack contains one battery with a bottom wheel and several batteries without a bottom wheel | |||
More model for choice:
| Model | Description |
| HY7K-15KWH-S | Equipped with 7KW Controller box, 15KWh battery pack, Single-phase output |
| HY7K-20KWH-S | Equipped with 7KW Controller box, 20KWh battery pack, Single-phase output |
| HY7K-25KWH-S | Equipped with 7KW Controller box, 25KWh battery pack, Single-phase output |
| HY7K-30KWH-S | Equipped with 7KW Controller box, 30KWh battery pack, Single-phase output |
| HY8K-15KWH-S | Equipped with 8KW Controller box, 15KWh battery pack, Single-phase output |
| HY8K-20KWH-S | Equipped with 8KW Controller box, 20KWh battery pack, Single-phase output |
| HY8K-25KWH-S | Equipped with 8KW Controller box, 25KWh battery pack, Single-phase output |
| HY8K-30KWH-S | Equipped with 8KW Controller box, 30KWh battery pack, Single-phase output |
| HY8K-20KWH-T | Equipped with 8KW High Voltage Controller box, 20KWh battery pack, 3-phase output |
| HY8K-25KWH-T | Equipped with 8KW High Voltage Controller box, 25KWh battery pack, 3-phase output |
| HY8K-30KWH-T | Equipped with 8KW High Voltage Controller box, 30KWh battery pack, 3-phase output |
| HY8K-35KWH-T | Equipped with 8KW High Voltage Controller box, 35KWh battery pack, 3-phase output |
| HY9K-15KWH-S | Equipped with 9KW Controller box, 15KWh battery pack, Single-phase output |
| HY9K-20KWH-S | Equipped with 9KW Controller box, 20KWh battery pack, Single-phase output |
| HY9K-25KWH-S | Equipped with 9KW Controller box, 25KWh battery pack, Single-phase output |
| HY9K-30KWH-S | Equipped with 9KW Controller box, 30KWh battery pack, Single-phase output |
| HY10K-15KWH-S | Equipped with 10KW Controller box, 15KWh battery pack, Single-phase output |
| HY10K-20KWH-S | Equipped with 10KW Controller box, 20KWh battery pack, Single-phase output |
| HY10K-25KWH-S | Equipped with 10KW Controller box, 25KWh battery pack, Single-phase output |
| HY10K-30KWH-S | Equipped with 10KW Controller box, 30KWh battery pack, Single-phase output |
| HY10K-20KWH-T | Equipped with 10KW High Voltage Controller box, 20KWh battery pack, 3-phase output |
| HY10K-25KWH-T | Equipped with 10KW High Voltage Controller box, 25KWh battery pack, 3-phase output |
| HY10K-30KWH-T | Equipped with 10KW High Voltage Controller box, 30KWh battery pack, 3-phase output |
| HY10K-35KWH-T | Equipped with 10KW High Voltage Controller box, 35KWh battery pack, 3-phase output |
| HY12K-20KWH-T | Equipped with 12KW High Voltage Controller box, 20KWh battery pack, 3-phase output |
| HY12K-25KWH-T | Equipped with 12KW High Voltage Controller box, 25KWh battery pack, 3-phase output |
| HY12K-30KWH-T | Equipped with 12KW High Voltage Controller box, 30KWh battery pack, 3-phase output |
| HY12K-35KWH-T | Equipped with 12KW High Voltage Controller box, 35KWh battery pack, 3-phase output |
| HY15K-20KWH-T | Equipped with 15KW High Voltage Controller box, 20KWh battery pack, 3-phase output |
| HY15K-25KWH-T | Equipped with 15KW High Voltage Controller box, 25KWh battery pack, 3-phase output |
| HY15K-30KWH-T | Equipped with 15KW High Voltage Controller box, 30KWh battery pack, 3-phase output |
| HY15K-35KWH-T | Equipped with 15KW High Voltage Controller box, 35KWh battery pack, 3-phase output |
