96V 300Ah Marine Lithium Battery with IP67 Waterproof and Stainless Steel Case for Electric Boats
Price:
Negotiable
MOQ:
1
Delivery Time:
Negotiable
Brand:
CLF or OEM
Product Description
CLF OEM ODM Electric Boat Marine EV Battery Pack 96V 144V 300Ah LiFePO4 Battery
High-performance lithium iron phosphate battery pack designed specifically for electric boats and yachts, offering reliable power and exceptional safety features.
Technical Specifications
| MODEL | CLF96300 |
| Cell Type - Chemistry | Prismatic - LiFePO4 |
| Rated Capacity | 304Ah |
| Rated Voltage | 96V |
| Energy | 29.18KWh |
| Resistance | 30mΩ |
| Self Discharge | <3% per month |
| PDU | BMS, 400A relays, fuses, COM socket |
| Dimensions (L x W x H) | L1300*W500*H380mm (Customizable) |
| Weight | 2540Kg |
| Enclosure Protection | IP67 stainless steel case |
| Discharge Cut-off Voltage | 75V |
| Max Continuous Discharging Current | 300A |
| Peak Discharge Current | 400A for 60 seconds |
| Recommended Discharge Current | 300A |
| Charging Limited Voltage | 109.5V |
| Max Charging Current | 200A |
| Recommended Charge Current | 100A |
| Charge Temperature Range | 0~50℃ |
| Discharge Temperature Range | -20~60℃ |
| Recommended Operating Temperature | 15~35℃ |
| Available on request | Size, C rate, Communication protocol |
Core Advantages
Advanced LiFePO4 Technology
Utilizing the safest LFP battery technology, our marine batteries offer superior performance with high energy density, long cycle life, low self-discharge rate, high discharge capability, fast charging, and exceptional safety. Provides reliable, efficient, and eco-friendly power for electric boats, enabling longer travel distances and smoother operation.
Laser Welding Technology
Advanced laser welding strengthens connections and eliminates screw failure risks. Reduces contact surface area between screws and bus bars to enhance current capability, lower internal resistance, and minimize power consumption.
Intelligent Battery Management System
Comprehensive protection and monitoring system including:
- Short-circuit protection
- Overcharge and over-discharge protection
- Over-temperature protection
- Cell balancing
- Temperature sensing and control
- State-of-charge (SOC) estimation
- Real-time monitoring and management
- Communication interface: CAN, RS485 optional
Stainless Steel IP67 Waterproof Enclosure
304/316 stainless steel case provides exceptional corrosion resistance, making it ideal for marine and industrial environments. The IP67 waterproof rating ensures rugged, long-lasting protection for battery packs in harsh conditions.
Optional Thermal Management System
Liquid cooling and heating system adapts batteries to various working environment temperatures. Battery thermal management regulates temperature to maintain optimal battery health and performance in electric vehicle systems.
Main Applications
Ideal power solution for various marine and electric vehicle applications:
