OEM ODM LiFePO4 30kwh marine battery pack 51.2V 280Ah lifepo4 battery for electric boat
Price:
Negotiable
MOQ:
2 unit
Delivery Time:
7-15 working days
Brand:
Chalong Fly
Product Description
OEM ODM LiFePO4 30kwh marine battery pack 51.2V 280Ah lifepo4 battery for electric boat
| MODEL | 48280 |
|---|---|
| Cell Type - Chemistry | Prismatic- LiFePO4 |
| Rated Capacity | 280Ah |
| Rated Voltage | 51.2V |
| Energy | 14.33KWh |
| Resistance | 30mΩ |
| Self Discharge | <3% per month |
| PDU | BMS, 400A relays, fuses, COM socket |
| Dimensions (L x W x H) | L1300*W500*H380mm (Can make it smaller if you want) |
| Weight | 2540Kg |
| Enclosure Protection | IP67 stainless steel case |
| Discharge Cut-off Voltage | 75V |
| Max Continuous Discharging Current | 280A |
| Peak Discharge Current | 400A for 60 seconds |
| Recommended Discharge Current | 280A |
| Charging Limited Voltage | 109.5V |
| Max Charging Current | 200A |
| Recommended Charge Current | 100A |
| Charge Temperature Range | 0~50℃ |
| Discharge Temperature Range | -20~60℃ |
| Recommended Operating Temperature | 15~35℃ |
| Available on request | Size, C rate, Communication protocol |
Product Highlights:
- High Capacity & Power: Delivers 14.33 kWh of energy with a robust 280A continuous discharge current, ideal for demanding applications.
- Wide Temperature Range: Operates reliably in harsh environments, from -20°C to 55°C discharge.
- Robust & Protected: IP65-rated cold-rolled steel enclosure ensures superior durability and protection against dust and water.
- Smart Communication: Integrated CAN bus enables seamless monitoring and integration with battery management systems (BMS) and inverters.
- Safety Built-in: Features precise voltage cut-offs and is designed for stable operation within specified thermal limits.
Primary Applications:
- Commercial & Industrial Energy Storage Systems (ESS)
- Large-scale Solar Backup Power
- Telecom Base Stations
- Low-Speed Electric Vehicles & Specialty Vehicles
Designed for reliability, built for performance. The CLF-48280 is your robust energy solution for stationary and mobile power needs. Contact us to integrate this pack into your system.
