12V 130Ah 1300CCA Marine Lithium Battery with IP67 Waterproof and Lightweight Design for Marine Starting
Price:
Negotiable
MOQ:
2 unit
Delivery Time:
7-15 working days
Brand:
Chalong Fly
Product Description
Boat Cranking 12V 130Ah Marine Starting Battery Lithium 1300CCA
Core Features
- 1300CCA powerful cranking current for instant starts in low temperatures
- 12V 130Ah large capacity for balanced cranking and auxiliary power
- IP67 waterproof and dustproof with salt spray corrosion resistance
- LiFePO4 core with intelligent BMS for comprehensive safety protection
- 60% lighter than lead-acid batteries for space-saving marine installation
This 12V 130Ah 1300CCA marine starting lithium battery utilizes high-performance LiFePO4 cells specifically engineered for marine starting systems. With 1300CCA strong cold cranking current, it delivers instant engine starts at -20℃, making it suitable for yachts, sailboats, fishing boats, workboats, and various marine vessels. Featuring IP67 full-sealed protection, salt spray and vibration resistance, and built-in intelligent Battery Management System (BMS), this battery ensures maximum cranking safety and stability while offering longer service life, lighter weight, and higher efficiency compared to traditional lead-acid starting batteries.
Technical Specifications
| Parameter Category | Parameter Name | Specification |
|---|---|---|
| Basic Parameters | Model No. | Marine-LF-12V130Ah-1300CCA |
| Battery Type | LiFePO4 (Lithium Iron Phosphate) | |
| Nominal Voltage | 12.8V | |
| Nominal Capacity | 130Ah (1664Wh) | |
| Performance Parameters | Cold Cranking Amps (CCA) | 1300A |
| Charging Voltage | 14.4V-14.6V | |
| Discharge Cut-off Voltage | 10.0V | |
| Max. Continuous Discharge Current | 130A | |
| Cycle Life (@80% DoD) | ≥2000 Cycles | |
| Performance Parameters | Charge/Discharge Efficiency | ≥95% |
| Physical Parameters | Product Dimensions (L*W*H) | 480*270*210mm |
| Net Weight | 18.5kg | |
| Casing Material | Aluminum Alloy (Anti-Corrosion, Flame-Retardant) | |
| Mounting Type | Horizontal/Vertical, with Mounting Holes | |
| Environmental Parameters | Operating Temp (Charging) | 0℃~45℃ |
| Operating Temp (Discharging) | -20℃~60℃ | |
| Protection Grade | IP67 | |
| Salt Spray Resistance | Complies with IEC 60068-2-11 Standard |
Safety & Reliability
Utilizing LiFePO4 cells with excellent thermal stability, this battery eliminates fire and explosion risks, making it ideal for confined marine spaces. The built-in intelligent BMS provides comprehensive safety protections including overcharge, over-discharge, over-current, short circuit, over-temperature, reverse connection prevention, and balanced charging. The system continuously monitors battery status to prevent damage and ensure safe operation.
Frequently Asked Questions
Q1: Can this battery directly replace marine lead-acid starting batteries?
A1: Yes, the 12V voltage is fully compatible with traditional lead-acid starting batteries. It can be directly installed without modifying marine circuits, offering lighter weight and superior starting performance.
Q2: Will starting performance be affected in low-temperature environments?
A2: No, the product supports low-temperature discharge at -20℃, and the 1300CCA strong cranking current ensures instant starts in cold environments, making it suitable for use in cold sea areas.
Q3: Is a special charger required?
A3: We recommend using a dedicated LiFePO4 charger (charging voltage 14.4V-14.6V) to prevent battery damage from overcharging. We can provide a dedicated charger as part of a complete set.
Q4: Can IP67 protection resist seawater immersion?
A4: Yes, the IP67 rating allows immersion in 1 meter of water for 30 minutes without water ingress. The casing features salt spray resistant coating to provide long-term protection against seawater corrosion.
