CLF 24V 60Ah Solar Energy Storage LiFePO4 battery for Solar Street Light Garden Light
Chalong Fly Public Battery Swapping Charging Station
Application to E-bike, Scooter, Motorcycle, Rickshaws
--The battery can be controlled remotely, and the battery can be turned off according to the actual situation.
--There is automatic fire extinguisher in each cabinet for emergency using.
| Item | Spec |
| Construction material | Carbon steel plate |
| Material thickness | 1.2mm |
| Appearance process | Painting silk printing |
| Optimum structure | Power push and pull battery |
| Single Slot bearing | 30Kg |
| Slot number | 12 |
| Move | Anti-skid roller,Bearing capacity of 800kg |
| Single Slot empty size | 260*230*400mm,Customizable |
| Cabinet size | 1100*600*1650mm |
| Weight | 175Kg |
| Input voltage | Output voltage | Input current | Rated input power | Rated output power | |||||||||||||||||
| 220VAC/ 176- 264VAC |
48～90VDC | ≤56A | 10000W | 750W | |||||||||||||||||
Environmental characteristics
| Item | Spec | Remark |
| Operating ambient temperature | 0℃ ~ 40℃ | 24H at full load, normal performance |
| Storage ambient temperature | -20℃ ~ 60℃ | 48H, normal temperature recovery |
| 2H, normal work | ||
| Operating ambient humidity | 10% ～ 90% | No condensation |
| Storage ambient humidity | 10% ～ 90% | No condensation |
| Above sea level | 2000m | No rated power reduction is achieved |
| below 2000m | ||
| Cooling mode | Air blast cooling | AC fan |
| IP Grade | IP54 | Suitable for outdoor use |
Input characteristics
|
Communication mode
|
Output characteristics
|
Technical Services
1, smoke sensor: when the fire just happened, smoke into the detector will trigger the alarm.
2, aerosol device: through the isolation of oxygen, heat absorption, cooling, interrupt the combustion of free radicals, fully submerged covering space, to achieve efficient fire extinguishing purpose
3, temperature sensor: when the temperature rises suddenly, the detector will send an alarm signal to the server to remind the management
4, intelligent electronic lock: scan code automatically unlock, add solid core, with electronic control lock 100,000 + times of use, durable
5, water immersion device: water immersion power, lightning leakage prevention, safety protection
6. FCL fan: FCL fan for temperature control and heat dissipation. When it reaches 40 degrees, open the fan heat dissipation; Turn off the fan when the temperature is lower than 40 ° C, saving energy
7, anti-theft ability: anti-theft door lock, built-in door, no exposed screws
8. Lightning protection ability: lightning protection and leakage prevention
9, waterproof level: IP56, the cabinet body waterproof structure, PCB board in the cabinet are coated with three anti-paint
10, windproof level: resistance to 60m/s wind
Application
It is used for takeout riders, logistics distribution, shared electric vehicles, batteries of the same specification, industrial parks, commercial centers, road parking points, etc
