Portable 7.2Wh Super Capacitor Pack , 200 Farad Capacitor Module
Price:
Negotiable
MOQ:
2 Pcs
Delivery Time:
5-8 work days
Brand:
Purple Horn
Product Description
Energizer Car jump Starter 16V 200F Graphene Super Capacitor for Charger Booster
| Model number: | GHT16V200FL |
| Place of origin: | Guangdong,Cn |
| Product name: | Super capacitor module/super capacitor pack |
| weight: | 3.5 kg |
| Working temperature: | -40~65℃. |
| ESR: | 3.7 mΩ |
| Leakage current | Less than 3.5mA |
| Charging and discharging time | More then 20000 times |
| Application | Energy storage/transportation car power/motor start /car start etc |
| Storage energy: | 7.2 wh |
| Maximum continuous current | 100A |
| Leakage current: | 3.5 mA |
| MOQ: | 2 Cet |
| Specification | 16v 200f |
| SIZE: | 417*68*122(Two sizes with different length, width and height) |
There is no conversion between Farad to an Amp-hour rating. Energy stored in a capacitance is calculated as 0.5CV^2 (result in joules, equivalent to watt-seconds) and in electrochemical cells estimated as the amp-hour rating multiplied by nominal cell voltage (result in watt-hours).
In terms of their function, the biggest difference between the capabilities of a battery cell and supercapacitor is that batteries have a higher energy density (meaning they can store more energy per unit mass), but supercapacitors have a higher power density (they can store and release more short-term power).
Supercapacitors are already used to rapidly charge the power supplies in hybrid buses as they go from stop to stop. Currently, such chargers aren’t commercially viable to deliver on a mass scale, but as more people buy electric cars the charging infrastructure is likely to develop to a point that widespread supercapacitor chargers become a reality.
But electric car systems, batteries, charging and tech are improving all the time, so the scope for supercapacitors to amp up future EVs is electrifying.
