Light Detection And Ranging Ldv Doppler Lidar Wind Survival Wind Speed 70m/S
Price:
Dollar 5W$+ （Price consultation customer service）
MOQ:
1 set
Delivery Time:
1-2 months
Brand:
MOVELASER
Product Description
Doppler wind light detection and ranging Survival Wind Speed 70m/s
| Product introduction
The optical antenna receives the backscattered signal, beats it with the internal local oscillator light of the system, and ultimately converts it into an electrical signal. After the signal is amplified, the digitization of the electrical signal is completed by an analog-to-digital converter A/D. The collected data is transmitted to the processor, and the radial wind speed at different distances of each beam is obtained based on the signal processing algorithm. Finally, the reconstructed wind speed, wind direction, turbulence, wind shear and other information are obtained by combining the wind field model.
| Application scenarios
Reduce fatigue load by 5%-10%
Reduce the ultimate load by 10%-15%
Extend fan life and reduce fan costs
Reduce the ultimate load by 10%-15%
Extend fan life and reduce fan costs
| Product parameters 参数
|
IP(Optical Head) |
IP66 |
|
IP(Data Unit) |
IP54 |
|
Sampling frequency |
4Hz |
|
Wind speed measurement range |
-50 ~50m/s |
|
Wind direction measurement range |
-180°～180° |
|
Wind speed accuracy |
0.1m/s |
|
Accuracy of wind direction |
±0.5° |
|
Laser form |
pulse wave |
| Product Features
True front wind measurement
Real time data transmission and local storage
Accuracy up to 0.1m/s and 0.5°
high sample rate
Multiple distance layers
large range
| Product Image
