Nl400 4 Beams 400m Wind Iris Lidar 0.1m/S 0.5° Accuracy Rental
Wind Iris Lidar NL400 4Beams 400m 0.1m/s 0.5° Accuracy Rental
| Product introduction
The data storage unit (PU) is a key component of Molas NL for data storage and external interaction, mainly consisting of power supply, data processing, data storage, and external interaction.
| Application scenarios
True front wind measurement
Real time data transmission and local storage
Accuracy up to 0.1m/s and 0.5°
high sample rate
Multiple distance layers
large range
| Product parameters
|
Beam Structure |
4 beams, horizontal angle 30°, vertical angle 25° (NL200) |
|
Number of measured sections |
10 |
|
Sampling frequency |
4Hz |
|
Wind speed measurement range |
-50 ~50m/s |
|
IP(Optical Head) |
IP66 |
|
Wind speed accuracy |
0.1m/s |
|
Accuracy of wind direction |
±0.5° |
|
Measurement layer |
Simultaneously measure and output 10 distance layers |
| Product Features
| Product Image
