1.25Gbps HGU Router GPON ONU 4GE Hgu Home Gateway IEEE802.3ah EPON Standard
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
1 month if no any stock
Brand:
BEHOME
Product Description
GPON ONU Router Overview
By introducing latest fiber GPON access technology, The BHU2104BW GPON ONU Router brings carrier class high-end networking solution for advanced triple play services. It compliant with ITU-T G.984 standard, dual-band wireless for combined connection speeds of up to 1200 Mbps(867 Mbps on 5GHz and 300 Mbps on 2.4 GHz) , Layer 2/3, and high quality VoIP as well, BHU2104BW GPON ONU Router support the comprehensive triple-play services, including voice, video (IPTV or VoD), and high-speed internet access service.
BHU2104BW XPON(4GE) GPON HGU
| EPON Interface | |
| Rate | Upsteam: 1.25Gbps Downsteam: 1.25Gbps |
| Interface standard | IEEE802.3ah EPON standard |
| Launch power | Min: 0dBm Max: +4dBm |
| Sensitivity | -27dBm |
| Input Power Overload | -7dBm |
| Service Interface | |
| EPON Interface | 1 EPON Port |
| Data Interface | 4 GE |
| POTS Interface | 1 FXS Port |
| WIFI Interface | IEEE 802.11 ac/n/g/b/a wireless LAN |
| USB Interface | USB 2.0 |
| Antenna Type | 4 external antennas |
| Environmental conditions | |
| Storage | temperature -10 to 70°C, rel. humidity 10–90% (non-condensing) |
| Operation | temperature 0 to 45°C, rel. humidity 10–90% (non-condensing) |
| Power Supply and Consumption | |
| Power Adaptor | Input: 100 to 240 V AC, 50/60 Hz; Output: 12 V, 1.5A |
| Consumption | ≤12W |
| Physical specifications | |
| Dimensions | 253mm×153mm×33mm(L×W×H) |
| Weight | 0.36KG |
| Recommand Devices List | ||
| Item Code | Item Name | Decription |
| BHU2104 | Simple GPON ONU without WIFI | 1GE+3FE |
| BHU2104W | XPON ONU(GPON/EPON/XPON/10GPON) | 2GE+2FE+1FXS+1USB |
| BHU2104BW | GPON ONU | 4GE+2FXS |
| BHU2000 | Wifi6 | 1GE WAN+3GE LAN |
| BOR1000AN | Economic Optical Receiver | |
| BOR1000BW | Economic Optical Receiver with WDM | |
| BOR1000BN | White Optical Receiver | |
| BOR1000DW | White Optical Receiver with WDM |
