JIS F7309 MARINE CAST IRON GLOBE VALVE 16K 2" to 14" DN50-DN450
Marine Cast Iron Globe Valve JIS F7309 16K
It is suitable for the pipe system with the medium fresh water, air & other gas, oil and steam with the temperature not over 205 centigrade degree.
Design Standard: JIS F7309-1996
Test Standard: JIS 7400-1996
Hydraulic Test Pressure: Body- 3.3Mpa, Seat-2.42Mpa
Flange size as per JIS B2220 - 16K
Main Material:
Body: Cast Iron (FC200)
Bonnet: Cast Iron (FC200)
Packing Gland: Bronze (BC6) or Stainless Steel (2Cr13)
Stem: C3771BD (Brass) or SUS403
Seat: Bronze (BC6) or Stainless Steel (2Cr13, SCS2)
Disc: Bronze (BC6) or Stainless Steel (2Cr13, SCS2)
Gasket: non-asbestos
IMPA 750261 F7309 16K50
IMPA 750262 F7309 16K65
IMPA 750263 F7309 16K80
IMPA 750264 F7309 16K100
IMPA 750265 F7309 16K125
IMPA 750266 F7309 16K150
IMPA 750267 F7309 16K200
Main Size List(mm): Marine Cast Iron Globe Valve JIS F7309 16K
| IMPA CODE | DN | L | D | C | No of bolt hole | h | t | H | D2 | Weight(kgs) |
| 750261 | 50 | 220 | 155 | 120 | 8 | 19 | 20 | 285 | 160 | 19.6 |
| 750262 | 65 | 270 | 175 | 140 | 8 | 19 | 22 | 310 | 200 | 28.3 |
| 750263 | 80 | 300 | 200 | 160 | 8 | 23 | 24 | 340 | 224 | 40.4 |
| 750264 | 100 | 350 | 225 | 185 | 8 | 23 | 26 | 385 | 250 | 56.9 |
| 750265 | 125 | 430 | 270 | 225 | 8 | 25 | 26 | 455 | 315 | 89.5 |
| 750266 | 150 | 500 | 305 | 260 | 12 | 25 | 28 | 510 | 355 | 123 |
| 750267 | 200 | 570 | 350 | 305 | 12 | 25 | 30 | 630 | 450 | 188 |
