Original Brocade 57-1000495-01 XBR-000462 64G MMF Fiber 300m 850nm Duplex LC Transceiver Module

The Brocade® 64G short wavelength (SWL) double-density optical transceiver (SFP-DD), part of the Brocade family of optical transceivers, is optimized for Brocade G720 and G730 device or ISL connectivity. Dual SN connectors from a single SFP-DD transceiver allow organizations to connect more servers, storage, or switches in a small footprint. Each transceiver supports two independent connections of a 64G Fibre Channel via a two-lane electrical interface. The Brocade 64G SWL SFP-DD transceiver is hot-swappable and supports high-speed serial links over multimode optical fiber at signalling rates up to 57.8Gb/s

Key Features

• Provides two optical connections in a single transceiver to support high-density SAN solutions

• Operates over duplex multimode fiber

• Uses industry-standard SN connectors.

• IEC 60825-1 Class 1/CDRH Class 1 laser, eye-safe.

• RoHS 6 compliant.

• Diagnostic features per SFF-8472, Diagnostic Monitoring Interface for Optical Transceivers, providing real-time monitoring of the following:

− Transmitted optical power

− Received optical power

− Laser bias current

− Temperature

− Supply voltage

Protocol

• 64G Fiber Channel​

​

Parameters

​​

FAQ

• Is this genuine Brocade Original Transceiver?

Yes, Topstar is the top lead Brocade distributor in China, we sell the brand SFP since 2006 and never sell fake or copy brand items.

• Hong long does your SFP quality warranty provide?

​

For brocade SFP, we support 30days of free return and 1 year of free replacement for any quality issues.

• How do you send me the SFP module? and how long does it take?

​
We provide door to door shipment via DHL, FEDEX, Aramex and UPS etc logistic services.

The express logistic generally takes 5-12 days to global.

​​

• Do you have regular stock of this Brocade transceiver?

​

Yes, we have regular stock of thousands of pcs, ready for a big volume order
