GLC-SX-MM Cisco SFP Module 1Gbps 500m MMF 850nm Duplex SFP

Price Negotiable
Price: Price is negotiable
MOQ: 1 pc
Delivery Time: within 24 hours
Brand: Cisco
Product Description

GLC-SX-MM Duplex SFP 1Gbps 500m MMF 850nm Optical Modules Transceiver



The features of GLC‐SX-MM

Connector LC
DDM No
Lasers FP
Tx power -3.0 to -9.5 dBm
Rx sensitivity -3.0 to -20.0 dBm
Extinction Ratio 3.4dB
Power Consumption 1.0W
Single Power Supply

3.3V











The Features of GLC‐SX-MM



  • 1000BASE-SX Ethernet SFP



  • Up-to 500m over MMF @ 1Gbps



  • 850nm Duplex SFP Transceiver



  • 0°C - 70°C Operating Case Temperature



  • No Digital optical monitoring capability



  • Hot-swappable for SFP LC ports



  • 30 days standard warranty



  • SFP can be covered by SMARTnet



  • SFP MSA / IEEE Std 802.3



  • GLC-SX-MM is RoHS compliant



The Applications of GLC‐SX-MM

  • Gigabit Ethernet



  • 1x Fiber Channel



  • Other optical links





The Description of GLC‐SX-MM

The GLC-SX-MM 1000BASE-SX Ethernet transceiver is a Duplex SFP transceiver for optical communications, rated for distances up to 500m and a maximum bandwidth of 1Gbps.

The GLC-SX-MM transceiver operates at 850nm wavelength.

The 1000BASE-SX SFP, compatible with the IEEE 802.3z 1000BASE-SX standard, operates on legacy 50 nm multimode fiber links up to 550 m and on 62.5 μm Fiber Distributed Data Interface (FDDI)grade multimode fibers up to 220 m.

It can support up to 1km over laser-optimized 50 μm multimode fiber cable.



FAQ



Q1. Are your Optical Transceivers original?



A1.Yes, all our optical transceivers are guaranteed 100% original!





Q2. What will you do if I found the product has any quality problem?



A2.We back up every sale with our risk-free money-back guarantee! You can buy with confidence from a company in good faith that has been serving its clients for over 10 years! Our dream is to build a famous 100 years enterprise!





Q3. How does your company do regarding quality control?


A3. We have professional testing equipment and QC team. Every unit will be double tested with perfect performance before shipping.





Q4. What are the trade terms?



A4.Lead Time: 1 day after confirm your payment (In stock, we need 1 day to fully test them)



Payment term: Western Union, T/T, Alipay, Escow, Money Gram



Warranty: 1 Year



Q5. Do you have compatible ones?



A5.Yes, we have our own brand:Top-trans, including 1X9,SFP, XFP, SFP+, BIDI in all kinds of specifications.
