Air Blow PVC Pcu Shoe Sole Injection Machine 400*280*230mm Hot Plate
Product Description
Company Info.
Customer Question & Answer
Basic Info.
Product Description
Pvc Shoes Air Blow Machine Pcu Shoes Machinery PVC Slipper Air Blowing injection Machine
Machine pic:
machine details
| Item | Unit | Specification |
| Number of work station | Stations | 24 |
| Screw length diameter ratio | L/D | 150-220 |
| Screw Diameter | mm | 60 |
| Max injection volume | cm³ | 785 |
| Max injection pressure | Kg/cm² | 140 |
| Mold Clamping Force | Tons | 70 |
| Mould space(L*W*H) | mm | 400*280*230 |
| Motor | kw/hp | 18.5/25 |
| Auto thermo controller | Sets | 4 |
| Heating bands power | Kw | 9.18 |
| Total electric consumption | Kw | 26.86 |
| Mould space(L*W*H) | m | 6.2*3.53*2.3 |
| Machine Weight | Tons | 8.8 |
Our Services
2. Engineers available to service machinery overseas
3. We also can offer the high quality second hand plastic injection machine, we change the main spare parts, so the machine looks almost new.
4. We are specialized in making Plastic injection moulds and can make new drawing according to customer,s request if any design need change.
5. We can offer many newly styles for you reference.
6. We also can offer the raw material for you according to your request.
This is KingKung Group Co.,Ltd., falling in line with shoes, shoe accessories, shoe mould, shoe material, and machinery.We introduce and offer the newest style and good quality products to our customers.Keeping serious quality control before
shipment.We offer good after-sales service, once you received the product, if there are any problems, inform us,and we are sure we can deal with that perfectly.
