Hydraulic Plastic PVC Injection Molding Shoe Machine Rotary
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
Product Description
Company Info.
Customer Question & Answer
Ask something for more details
Basic Info.
Model NO.
OY-808P
Work Station
8
Machine Dimension(Lxwxh)
7.1*2.8*2.3m
Max. Injection Speed
10cm/Sec
Transport Package
Film
Specification
7.1*2.8*2.3m
Trademark
kingkung
Origin
Quanzhou
Production Capacity
100sets /Month
Product Description
rotary plastic shoe injection molding machine
machine pic:
![Rotary Plastic Shoe Injection Molding Machine]()
MATERIAL:PVC
WORK STATION:8
SCREW DIAMETER:D70mm
MAX. INJECTION VOLUME: 1450cm3
MAX. INJECTION PRESSURE: 680kg/cm2
MAX. INJECTION SPEED: 10cm/sec
HYDRAULIC MOTOR:600cc
MOTOR POWER: 41kw/HP
HEATING POWER: 10.1kw
TOTAL ELECTRIC CONSUMPTION:51.2kw
CLAMPING FORCE: 100tons
CLAMPING FORCE FOR MOLD STATION:3tons
MOLD DIMENSION(LxWxH): 400*300mm
MOULD HEIGHT: 200mm
MACHINE DIMENSION(LxWxH): 7.1*2.8*2.3m
MACHINE WEIGHT: 10tons
1. Many brands for you choose
2. Engineers available to service machinery overseas
3. We also can offer the high quality second hand plastic injection machine, we change the main spare parts, so the machine looks almost new.
4. We are specialized in making Plastic injection moulds and can make new drawing according to customer,s request if any design need change.
5. We can offer many newly styles for you reference.
6. We also can offer the raw material for you according to your request.
If any new inquiry, pls feel free contact with us! We will offer you the high quality products, good service with competitive price!
machine pic:

MATERIAL:PVC
WORK STATION:8
SCREW DIAMETER:D70mm
MAX. INJECTION VOLUME: 1450cm3
MAX. INJECTION PRESSURE: 680kg/cm2
MAX. INJECTION SPEED: 10cm/sec
HYDRAULIC MOTOR:600cc
MOTOR POWER: 41kw/HP
HEATING POWER: 10.1kw
TOTAL ELECTRIC CONSUMPTION:51.2kw
CLAMPING FORCE: 100tons
CLAMPING FORCE FOR MOLD STATION:3tons
MOLD DIMENSION(LxWxH): 400*300mm
MOULD HEIGHT: 200mm
MACHINE DIMENSION(LxWxH): 7.1*2.8*2.3m
MACHINE WEIGHT: 10tons
