Product Description
Product Description
6 stations single color rotary TPU sole injection machine shoe outsole making machine| station | station | 6 |
| Injecting screw diameter | mm | Φ50 |
| Max.injecting Capacity | Cm3/shot | 390 |
| Clamping force | ton | 150 |
| Max.injecting pressure | Kg/cm2 | 1300 |
| Productivity per hour | Pair/h | 80-120 |
| Mould dimension | mm | 500*340*170 |
| Total power | kw | 33kw |
| Machine dimension | m | 2.8*2.1*2.9 |
| Machine weight | ton | 7 |
| Oil consumption | L | 500 |
Machine pic
Our Services
1. Many brands for you choose
2. Engineers available to service machinery overseas
3. We are specialized in making Plastic injection moulds and can make new drawing according to customer,s request if any design need change.
4. We can offer many newly styles for you reference.
5. We also can offer the raw material for you according to your request.
This is KingKung Group Co.,Ltd., falling in line with shoes, shoe accessories, shoe mould, shoe material, and machinery.We introduce and offer the newest style and good quality products to our customers.Keeping serious quality control before
shipment.We offer good after-sales service, once you received the product, if there are any problems, inform us,and we are sure we can deal with that perfectly.
