OD 30 Inch Tractor Mounted Agricultural Boom Sprayer 80hp 3W-800-12
YTO Agriculture boom sprayer boom sprayer tractor mounted pump sprayer 3W-800-12
Boom Sprayer, Agricultural Sprayer, Tractor Mounted Sprayer, Agricultural Boom Sprayer
Production Description:
3W series of sprayer is suitable for spraying the medicament for the planter of bean, corn, cotton, grain. Also for lawn, fruite, vegetable, road side tree. The capacity could be 200L-1200L, the spraying width could be 6m-12m with 12-120hp tractor.
Advantages:
♦ This kind of boom sprayer is a tractor mounted sprayer.
♦ Wide working scope,spraying for bean,cotton,corn etc.
♦ Wide spraying with to be 12m max.and the working angle of this tractor sprayer could be adjusted.
♦ The capacity of mounted boom sprayer could be adjusted to meet different need from the user.
Product parameter:
| Model | Unit | 3W- | |||||
| 300 | 400 | 500 | 700 | 900 | 1000 | ||
| Working width | m | 6 | 10/12 | ||||
| Case volume | L | 300 | 400 | 500 | 700 | 900 | 1000 |
| PTO Rotation speed | r/min | 540 | |||||
| PTO shaft spline | 6 spline | ||||||
| Total weight | kg | 90 | 130 | 240/270 | 310/340 | 350/380 | 380/400 |
| Matched power | hp | 20-30 | 30-45 | 50-70 | 60-80 | 70-90 | 70-100 |
| Linkage | Three-point suspension I(II)type | ||||||
