VIIP VIP4-1A-03 3A Ultra Low Leakage EMI Filter for Medical Lab Instruments EMC Noise Filter
Price:
USD4.4
MOQ:
120PCS
Delivery Time:
31days
Brand:
Weiaipu
Product Description
VIIP VIP4-1A-03 3A 1-Phase Wire Lead EMI Filter
High-performance EMI filter designed for medical and laboratory instruments requiring ultra low leakage current and reliable EMC noise suppression.
- Current Rating: 3A
- Phase: 1-Phase
- Voltage: 115/250VAC
- Configuration: Wire Lead
- Filter Type: RC-LC EMC Noise Filter
- Leakage Current: Ultra Low
Applications: Medical equipment, laboratory instruments, and sensitive electronic devices requiring superior EMI/RFI suppression with minimal leakage current.
Electrical Characteristics
| Parameter | Value |
|---|---|
| Voltage Rating | 115/250 VAC |
| Current Rating at 115VAC | 3A RMS Max. |
| Current Rating at 250VAC | 3A RMS Max. |
| Operating Frequency | 50/60 Hz |
| Leakage Current at 115VAC/60Hz | 0.25 mA Max. |
| Leakage Current at 250VAC/50Hz | 0.45 mA Max. |
| Hi-pot Rating | (For One Minute) |
| IR (Insulation Resistance) | 100M ohm AT 500VDC, ANY Input or Output to Ground |
| Temperature Range | -25°C ~ +100°C |
Insertion Loss Performance
| MHz (频率) | 0.15 | 0.5 | 1 | 5 | 10 | 30 |
|---|---|---|---|---|---|---|
| COM.MODE (共模) | 28 | 36 | 39 | 45 | 48 | 39 |
| DIFF.MODE (差模) | 8 | 19 | 27 | 58 | 65 | 15 |
Electrical Schematic
Product Details
FAQs
Q1: What are the electrical specs, filtering performance, safety index and installation way of VIP4-1A-03?
A1:
A1:
Q2: Can I get VIP4-1A-03 samples for EMC lab testing?
A2: Sample testing is available.
A2: Sample testing is available.
Q3: What safety and environmental certifications does VIP4-1A-03 have?
A3: VIP4-1A-03 owns CE, UL, CQC, TUV,CB, RoHS and REACH certificates.
A3: VIP4-1A-03 owns CE, UL, CQC, TUV,CB, RoHS and REACH certificates.
Q4: Can you recommend suitable EMI filter models based on my equipment such as medical analytical instruments and portable precision test devices?
A4: Yes. Please inform us your equipment rated current, working voltage, equipment type and actual interference performance. We will recommend the most matching filter model and attach wiring & installation notes for your application scene.
A4: Yes. Please inform us your equipment rated current, working voltage, equipment type and actual interference performance. We will recommend the most matching filter model and attach wiring & installation notes for your application scene.
Q5: Can your engineers provide free EMC interference analysis and rectification suggestions for our equipment?
A5: Absolutely. Our professional EMC R&D team can analyze your equipment power interference problems according to your circuit structure and test phenomenon, provide free filtering optimization schemes to help you whole machine pass EMC certification smoothly.
A5: Absolutely. Our professional EMC R&D team can analyze your equipment power interference problems according to your circuit structure and test phenomenon, provide free filtering optimization schemes to help you whole machine pass EMC certification smoothly.
