4.3 Inch TFT Resistive Touch Screen 480x272 RGB 40 PIN Interface
HG043HV002R03: 4.3in is a TFT resistive touch screen with RGB 40 PIN interface, TFT, TN 6 0’clock ultra-wide view, resolution 480*272
4.3in is a TFT resistive touch screen with RGB 40 PIN interface, TFT, TN 6 0’clock view, display effect is ultra-wide view, resolution 480*272, matching industrial resistive touch screen, super anti-interference, used in industrial instruments, meters and other related industries.
Product parameter details
| Model | HG043HV002R03 | Application industry | Industrial instruments |
| Size/inch | 4.3-inch | Arrangement | 480*272 |
| Display size | 95.04mm*53.86mm | External dimensions | 105.5mm*67.2mm*4.2mm |
| Viewing Angle | TN 6 0' clock ultra-wide view | Luminance | 300cd/m2(customizable) |
| Contrast ratio | 500 | NTSC | 52% |
| TP structure | RTP | Cover plate | ITO Industrial glass |
| Signal types | RGB interface 40PIN | ||
| Temperature | Operating temperature:-20℃~70℃,storage temperature:-30℃~80℃ | ||
| Remark | Can be used for related instruments and equipment, ultra wide Angle of view | ||
Description of Products
HG043HV002R03 is a projection line color active matrix LCD display
It is composed of TFT LCD panel, driver IC, FPC, backlight and RTP
It has 480*272 resolution and displays an ultra-wide viewing Angle resistive touch display
This product is widely used in industrial control, medical, handheld, security, vehicle, instrumentation and other related products
All products are available with or without touch and industrial drive boards, no matter what configuration you choose,
All can be customized according to your requirements (can be customized backlight, FPC, touch screen, industrial driver board)
Comply with RoHS and CE certification standards
If you can't find one, please contact us for a recommendation
Packing and shipping
Packing details:
1. All products are packaged in the correct way to ensure safety.
2. For small size products, we use pallets = cartons.
3. For larger sizes, we use knife card + foam + carton.
4. We can also design packaging according to customer's requirements.
Transport:
1. By express (3-7 working days), suitable for emergency time and small amount.
2. By sea (15-30 days), suitable for routine mass production.
3. By air (4-5 days), from airport to airport.
