5 Inch Full View Industrial Capacitive Touch Screen Resolution 720x1280
HG050HD035T01: 5 Inch is MIPI interface, TFT, full view, resolution 720*1280 TFT capacitive touch screen
Product description
5 inch is MIPI interface, TFT, full view, resolution 720*1280 TFT capacitive touch screen,Used for security equipment, security instruments, security monitoring.
Product parameter details
| Model | HG050HD035T01 | Application industry | security equipment |
| Size | 5 inch | Arrangement | 720*1280 |
| Display size | 62.1mm*110.4mm | External dimensions | 72.76mm*129.9mm*3.25mm |
| Viewing Angle | ALL | Luminance | 420cd/m2(customizable) |
| Contrast ratio | 1000 | NTSC | 70% |
| Signal types | MIPI interface 25PIN | ||
| Temperature | Operating temperature in: -20℃ ~70℃, storage temperature: -30℃ ~80℃ | ||
| TP structure | G+FF | Cover plate | 1.1mm Corning III |
| TP IC | GT911 | TP interface | I²C |
| Remark | |||
Description of products
HG050HD035T01 is a projective row color active matrix LCD screen
It is composed of TFT LCD panel, driver IC, FPC, backlight source and CTP.
It is 720*1280 resolution circular structure,TFT capacitive touch screen , using MIPI interface 25PIN t,he main advantage is to provide a high quality package
This product is widely used in industrial control, medical, handheld, security, vehicle, instrumentation and other related products
All products are available with or without touch and industrial drive boards, no matter what configuration you choose,
Can be customized according to your requirements (can be customized backlight, FPC, touch screen, industrial drive board)
Comply with RoHS and CE certification standards
If you can't find a suitable one, please contact us for a recommendation
Packing and Shipping
Packing Details:
1. All products are packed in the correct way to ensure safety.
2. For small size products, we use pallets = cartons.
3. For larger sizes, we use knife card + foam + carton.
4. We can also design packing according to customer's requirement.
Transport:
1. By express delivery (3-7 working days), applicable to emergency time and small amounts.
2. Sea transportation (15-30 days), suitable for conventional mass production.
3. Airfreight (4-5 days), from airport to airport.
