10.1 G+G Structure TFT LCD Display 1200x1920 0.7mm Dragon Trace II Cover Plate
10.1 inch is G+G structure, 0.7mm Dragon Trace II cover plate, resolution of 1200*1920 TFT LCD touch Screen
Product description
10.1 inch is G+G structure, 0.7mm Dragon Trace II cover plate, surface hardness ≥7H, resolution of 1200*1920, industrial drive ILI2511, super anti-interference TFT LCD touch screen, widely used in industrial control, electronic equipment, industrial instruments and other related products
Product parameter details
| Model | CTP-HG101WU008T01 | Application industry | Industrial handheld |
| Size | 10.1 inch | Arrangement | 1200*1920 |
| Display size | 136.16mm*217.38mm | External dimensions | 148.4mm*253.4mm*1.45mm |
| luminousness | ≥80% | Surface hardnes | ≥7H |
| Temperature | -20℃~+70℃ | ||
| TP structure | G+G | Cover plate | 0.7mm Dragon mark ii |
| TP IC | Industrial ILI2511 | TP interface | I²C |
| Remark | Industrial grade driver chip supports wide temperature environment | ||
Description of Products
This 10.1 inch CTP-HG101WU008T01 capacitive touch screen
It is composed of cover plate,TP Sensor, FPC,IC, industrial grade IC, supporting wide temperature environment
Using IIC interface, ZIF 6PIN, can work at -20~70 temperature
Widely used in industrial control, medical, handheld, security, vehicle, instrumentation and other related products
Lens,FPC, Sensor and driver chip can be customized according to your requirements. The model can be selected according to special technical indicators (such as wet hand, gloves, active pen, explosion-proof, electromagnetic interference, wide temperature)
Comply with RoHS and CE certification standards
If you can't find a suitable one, please contact us for a recommendation
Packing and Shipping
Packing Details:
1. All products are packed in the correct way to ensure safety.
2. For small size products, we use pallets = cartons.
3. For larger sizes, we use knife card + foam + carton.
4. We can also design packing according to customer's requirement.
transport
1. By express delivery (3-7 working days), applicable to emergency time and small amounts.
2. Sea transportation (15-30 days), suitable for conventional mass production.
3. Airfreight (4-5 days), from airport to airport.
