ISO Cobalt Nickel Tungsten Carbide Bushing

Tungsten carbide is an inorganic chemical compound which contains numbers of tungsten and carbon atoms. Tungsten carbide, also known as “cemented carbide”, “hard alloy” or “hardmetal”, is a kind of metallurgic material which contains tungsten carbide powder (chemical formula: WC) and other binder (cobalt, nickel. etc.).

Tungsten carbide bearing bush shows high hardness and transverse rupture strength, and it has superior performance on resisting abrasion and corrosion, which enable it to be widely used in many industries.

The tungsten carbide bearing bush sleeve will be used mainly for rotating support, aligning, anti-thrust and seal of the axle of motor, centrifuge, protector and separator of the submerged electric pump in the adverse working conditions of high speed rotating, sand lash abrasion and gas corrosion in the oil field, such as slide bearing sleeve, motor axle sleeve and seal axle sleeve.

Cemented carbide sleeve adopts raw and auxiliary materials such as primary saturated tungsten carbide, high-purity ultra-fine cobalt powder, precise carbon blending, tilt ball milling, vacuum stirring drying, precision pressing, digital degreasing sintering and pressure sintering personalized post-processing and other advanced powder metallurgy processes. Hard alloy sleeve is widely used in special pump industry, with long service life and reliable quality.

Bearing bush sleeves are working in an abrasive environment due to rotation, friction, etc. and the particles involved in the media.

Tungsten carbide bushing sleeve with wear and corrosion resistance and a high fracture toughness for demanding axial thrust, and could meet API standard disaster bushing requirement.
