904L Stainless Steel Bar Added Strong Acids Resistance With Copper
Product Description
Grade 904L stainless steel is a non-stabilized austenitic stainless steel with low carbon content. This high alloy stainless steel is added with copper to improve its resistance to strong reducing acids, such as sulphuric acid. The steel is also resistant to stress corrosion cracking and crevice corrosion. Grade 904L is non-magnetic, and offers excellent formability, toughness and weldability.
Grade 904L contains high amounts of expensive ingredients, such as molybdenum and nickel. Today, most of the applications that employ grade 904L are replaced by low-cost duplex stainless steel 2205.
Physical Properties:
The physical properties of grade 904L stainless steels are tabulated below:
Grade |
Density (kg/m3) |
Elastic Modulus(GPa) |
Mean Co-eff of Thermal Expansion(µm/m/°C) |
Thermal Conductivity(W/m.K) |
Specific Heat 0-100℃(J/kg.K) |
Elec Resistivity (nΩ.m) |
|||
904L |
7900 |
190 |
0-100℃ |
0-315℃ |
0-538℃ |
AT 20℃ |
AT 50℃ |
500 |
952 |
15 |
- |
- |
11.5 |
- |
|||||
Grade Specification Comparison:
The following table outlines the approximate grade comparisons of 904L stainless steels:
Grade |
UNS No. |
Old British |
Euronorm |
|
|
||
904L |
N08904 |
BS |
En |
No. |
Name |
Swedish SS |
Japanese JIS |
904s13 |
- |
1.4539 |
X1NiCrMoCuN25-20-5 |
2562 |
- |
||
Chemical composition
| Grade | C | Si | Mn | Cr | Ni |
| 304 | ≤0.07 | ≤1.00 | ≤2.0 | 18.00~20.00 | 8.00~10.50 |
| 304L | ≤0.030 | ≤1.00 | ≤2.0 | 18.00~20.00 | 9.00~13.00 |
| 310S | ≤0.08 | ≤1.00 | ≤2.0 | 24.00~26.00 | 19.00~22.00 |
| 316 | ≤0.08 | ≤1.00 | ≤2.0 | 16.00~18.00 | 10.00~14.00 |
| 316L | ≤0.03 | ≤1.00 | ≤2.0 | 16.00~18.00 | 12.00~15.00 |
| 321 | ≤0.08 | ≤1.00 | ≤2.0 | 17.00~19.00 | 9.00~13.00 |
| 904L | ≤0.02 | ≤1.00 | ≤2.00 | 19.00~23.00 | 23.00~28.00 |
| 2205 | ≤0.03 | ≤1.00 | ≤2.0 | 22.00~23.00 | 4.5~6.5 |
| 2507 | ≤0.03 | ≤0.08 | ≤1.20 | 24.00~26.00 | 6.00~8.00 |
Advantages of stainless steel angle bar:
1. Wide Specifications Range;
2. Pure steel chemical composition;
3. Outstanding mechanical properties;
4. Good performance after welding;
5. Good shape and high precision;
6. Excellent corrosion-resistant and long service life.
Packaging & Shipping
Common Package:
Waterproof Kraft Paper + Wooden Pallet (each 3 tons) + Bundle with steel strip.
Or Package can also according to your requirements.
The time of delivery:
Within 7-10 days after receipt of advance payment
FAQ
Q1:Can you send samples?
A:Of course, we can provide customers with free samples and express shipping service to all over of the world.
Q2:What product information do I need to provide?
A:Please kindly provide the grade, width, thickness, surface treatment requirement should you have and quantities you need to purchase.
