As an acclaimed undertaking of the business, Stainless Steel 304/304L/304H Bars (SS 304/304L/304H Bars) is austenitic steel by method for having non-attractive elements in the tempered structure that offers fantastic consumption imperviousness to both environmental and concoction exposures, in the organization of a raised imperviousness to oxidation.

Stainless Steel 304/304L/304H Rods (SS 304/304L/304H Rods) has great framing and great welding highlights.

As for national and worldwide nature of crude materials, we likewise offer these UNS S30400/S30403/S30409 Round Bars (otherwise called WNR 1.4301/1.4306 Bars) in tweaked sizes and thicknesses according to particular requests by our regarded customers at business sector driving costs.



Product name		SS 201 304 316 410 420 2205 316L 310S Stainless Steel Round / flat Bar
Material		304,304L,309S,310S,316,316L,316Ti,317,317L,321,347H,201,202,405,409, 410,420,430,etc
Type		Round,square,hexagonal,flat,angle
Surface		Pickled,Black,Bright,Polishing,Blasting,etc
Specification	Round bar	Diameter: 3mm~800mm
	Angle bar	Size: 3mm*20mm*20mm~12mm*100mm*100mm
	Square bar	Size: 4mm*4mm~100mm*100mm
	Flat bar	Thickness: 2mm~100mm
		Width: 10mm~500mm
	Hexagonal	Size: 2mm~100mm
Quality test		we can offer MTC (mill test certificate)
MOQ		500 kilograms
Payment terms		L/C T/T (30%DEPOSIT)
Stock or not		enough stock
Packing		Bundled,wooden box for export standard package
Delivery time		7-15 dyas,or according to the order quantity or upon negotiation



304/304L/304H Stainless Steel Round Bar Specification



Standard	304/304H / 1.4301 304L /1.4307
Designation	ASTM, ASME, AISI A 276 , SA 276, A 479, SA 479
Range	3 MM TO 350 MM DIA
Finish	Bright, Polish & Black
Form	Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc.
Application	Most commonly used in petroleum refineries, Boilers, Heat exchangers, Condensers, Pipelines, Cooling towers, Steam exhausts, Electric generation plants, On occasion will be found in fertilizer and chemical plants.



Grade	C	Mn	Si	P	S	Cr	Mo	Ni	N
304 304 L 304 H	0.07max 0.03max 18.0-20.0	2.0max 2.0max 8.0-10.5	0.75max 0.75max 0.04-0.10	0.045max 0.045max 0.75 max	0.03max 0.03max 2.0max	18.0- 20.0 18.0-20.0 0.045max	- - -	8.0-10.5 8.0-12.0 0.03max	- 0.10max 0.10max



The mechanical properties of grade 304/304L/304H Stainless Steel Round Bar are displayed in the following table.

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB)
					max
304	75	30	40	92	201
304L	70	25	40	92	201
304H	75	30	40	92	201

•   304/304L/304H Stainless Steel Round Bar Used in Tractor
•   304/304L/304H Stainless Steel Round Bar Used in Automotive Trim
•   304/304L/304H Stainless Steel Round Bar Used in Stamped Machined Products
•   304/304L/304H Stainless Steel Round Bar Used in Cookware
•   304/304L/304H Stainless Steel Round Bar Used in Appliances
•   304/304L/304H Stainless Steel Round Bar Used in Kitchen
•   304/304L/304H Stainless Steel Round Bar Used in Foodservice Equipment
•   304/304L/304H Stainless Steel Round Bar Used in Sinks
•   304/304L/304H Stainless Steel Round Bar Used in Railway Cars
•   304/304L/304H Stainless Steel Round Bar Used in Trailers

Cut large coils into small coils or Strip.
For steel coils, we can cut one large steel coil into small steel coils for loading at seaport; because for container shipping, each container usually loads weight can not be over 26 tons, but each large coil is usually about 28 tons, so one large coils has to be cut into small coils, and because the forklift usually takes 7-10 tons at seaport, so for easy loading into conatiner, each large steel coil usually is cut into 3 small coils. For bulk vessel shipping, it usually demands coils weight under 18 tons, so most times, also need cut one large coil into 2 small coils.
Open flat coils into steel plate.
For final application, need open flat the coils and cut the coils into steel plate, so we open flat the coils and cut the coils to steel plate to the sizes as required. For saving cost for loading by container, load into 20 feet containers, so cut the length under 5800mm, usually as required to cut to length 2440mm and 5800mm, width usually be 1220mm and 1500mm.after cutting the steel coils into steel plate, we can do black paints on the surface of the plate to make the plate to be anti-rust.
