FSCUT 2000C Cypcut Fiber Laser Cutting Machine Laser Controller System

Basic introduction

FSCUT2000C medium power laser cutting system is a full-solution open-loop control system specially designed for sheet metal fabricaton industry, with features of easy to install and adjust, excellent performance and fully integrated solutions

Feature

1.Craft
Supports five levels of perforation, any combination of segmented or progressive.

Support the communication control of most mainstream lasers on the market.

Support basic processes such as flying cutting, leapfrog, compensation, lead wire, micro-connection, pre-piercing, and film cutting.

Support capacitor edge seeking, photoelectric edge seeking, electric focusing, double exchange table, automatic layout, tube cutting, power-off memory, QR code, cutting line, maintenance and other advanced functions.

Support advanced processes such as cooling point, sharp corner girth, release corner, etc.

Support pre-opening, gas flushing.

Support starting, closing and fine cutting processes.

Support air-moving obstacle avoidance, leapfrog intelligent judgment.

Supports automation applications such as simple scheduling, virtual multi-station, and scanning code.

2.Control
Open-loop control system, the third-generation motion control algorithm of Bochu.

Track accuracy 0.03mm, positioning accuracy 0.001mm, repeat positioning accuracy 0.003mm.

The maximum cutting speed is 80m/min, and the maximum air moving speed is 150m/min.

Maximum acceleration 1.5G.

Support dual drive error detection function.

Applicable Industries

Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company

FSCUT 2000C
