Sch 80 316 Stainless Steel Seamless Pipe Stainless Steel Tubing
SS316 Seamless Pipe Description
316 stainless steel seamless pipe is a seamless pipe made of 316 stainless steel with excellent corrosion resistance and high strength, commonly used in pipeline systems in chemical, petroleum, pharmaceutical, food processing and other industries.
316 stainless steel is a stainless steel material with good corrosion resistance. It has good oxidation resistance and corrosion resistance and can maintain stable chemical properties in a variety of corrosive media. 316 stainless steel contains 17% chromium and 2.5% molybdenum,has good oxidation resistance and can be used stably for a long time in oxidizing media.
Stainless Steel 316 Pipes Specifications
| Product Name | Stainless Steel Pipe |
| Steel grade | 200 series,300 series,400 series |
| Standard | ASTM A213,A312,ASTM A269,ASTM A778,ASTM A789,DIN 17456, DIN17457,DIN 17459,JIS G3459,JIS G3463,GOST9941,EN10216, BS3605,GB13296 |
| Surface | Polishing,annealing,pickling,bright |
| Technique | Hot rolled / cold rolled |
| stainless steel round pipe/tube | Wall thickness: 1mm-150mm(SCH10-XXS) Outer diameter: 6mm-2500mm (3/8"-100") |
| Length | 4000mm,5800mm,6000mm,12000mm,or as required. |
| Application | Widely used in petroleum,foodstuff,chemical industry,construction, electric power,nuclear,energy,machinery,biotechnology,paper making,shipbuilding,boiler fields. Pipes also can be made according to the customer's required. |
| Package | Standard export seaworthy package,or as required. |
Seamless 316 Stainless Steel Tubing Surface Treatment
There are various surface finishes available for stainless steel pipes, such as 2B, BA, No. 4, HL, and others.
316 Stainless Steel CHEMICAL COMPOSITION
| Grade | C | Si | Mn | P | S | Ni | Cr | Mo |
| 316 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 |
SS316 Seamless Pipe Size
NPS | OD | SCH 5S | SCH 10S | SCH 40S | SCH 80S |
1/4 | 13.72 | – | 1.65 | 2.24 | 3.02 |
3/8 | 17.15 | – | 1.65 | 2.31 | 3.2 |
1/2 | 21.34 | 1.65 | 2.11 | 2.77 | 3.73 |
3/4 | 26.67 | 1.65 | 2.11 | 2.87 | 3.91 |
1 | 33.4 | 1.65 | 2.77 | 3.38 | 4.55 |
1.25 | 42.16 | 1.65 | 2.77 | 3.56 | 4.85 |
1.5 | 48.26 | 1.65 | 2.77 | 3.68 | 5.08 |
2 | 60.33 | 1.65 | 2.77 | 3.91 | 5.54 |
2.5 | 73.03 | 2.11 | 3.05 | 5.16 | 7.01 |
3 | 88.9 | 2.11 | 3.05 | 5.49 | 7.62 |
3.5 | 101.6 | 2.11 | 3.05 | 5.74 | 8.08 |
4 | 114.3 | 2.11 | 3.05 | 6.02 | 8.56 |
5 | 141.3 | 2.77 | 3.4 | 6.55 | 9.53 |
6 | 168.28 | 2.77 | 3.4 | 7.11 | 10.97 |
8 | 219.08 | 2.77 | 3.76 | 8.18 | 12.7 |
10 | 273.05 | 3.4 | 4.19 | 9.27 | 12.7 |
12 | 323.85 | 3.96 | 4.57 | 9.53 | 12.7 |
14 | 355.6 | 3.96 | 4.78 | 9.53 | 12.7 |
16 | 406.4 | 4.19 | 4.78 | 9.53 | 12.7 |
18 | 457.2 | 4.19 | 4.78 | 9.53 | 12.7 |
20 | 508 | 4.78 | 5.54 | 9.53 | 12.7 |
22 | 558.8 | 4.78 | 5.54 | – | – |
24 | 609.6 | 5.54 | 6.35 | 9.53 | 12.7 |
26 | 660.4 | – | – | – | – |
28 | 711.2 | – | – | – | – |
30 | 762 | 6.35 | 7.92 | – | – |
 |  |
 |  |
Stainless 316 Pipe Application
316 stainless steel has good anti-wear properties and can resist fluid impact and friction, extending the service life of the pipeline,widely used in pipeline systems in chemical, petroleum, pharmaceutical, food processing, aerospace and other fields, and are especially suitable for occasions that require high corrosion resistance of materials.
Stainless Steel 316 Pipes Packing:Standard export seaworthy package,or as required.
Shipping Port:Tianjin,Shanghai,Qingdao port,or as required
