NM360 Hot Rolled Wear Resistant Steel Plate High Toughness
Wear Steel Plate Description:
Hot rolled wear resistant steel plate is a special plate for use under large-area wear conditions. The commonly used wear-resistant steel plate is a plate material made of a certain thickness of alloy wear-resistant layer with high hardness and good wear resistance by surfacing welding on the surface of ordinary low carbon steel or low alloy steel with good toughness and plasticity.
We provide various grades and specifications of wear-resistant steel plates,available in NM360,NM400,NM450,NM500,NM600,etc. NM360 wear-resistant steel plate is a high-strength, wear-resistant structural steel plate with excellent wear resistance and high strength,can withstand large impact and pressure,suitable for high-load working environments and is widely used in mining, construction, metallurgy, machinery manufacturing and other fields.
|
Grade |
Thickness (mm) |
tensile strength(MPa) |
Elongation A(%) |
Surface Brinell hardness(HBW) |
|
NM300 |
≤80 |
≥1000 |
≥14 |
270-330 |
|
NM360 |
≤80 |
≥1100 |
≥12 |
330-390 |
|
NM400 |
≤80 |
≥1200 |
≥10 |
370-430 |
|
NM450 |
≤80 |
≥1250 |
≥7 |
420-480 |
|
NM500 |
≤70 |
- |
- |
≥470 |
Wear Resistant Plate Specification
Description:Wear resistant steel plate
Material Grade:NM360,NM400,NM450,NM500,NM600,etc
Thickness:2mm-300mm
Width:500-2500mm
Length:1000mm-12000mm
Technical Test:UT Test, Bending Test, Charpy Test
Technique:Hot Rolled
Processing Service:Welding, Punching, Cutting, Bending, Decoiling
Wear resistant plate has high wear resistance and good impact performance, can be cut, bend, welding, etc., can take welding, plug welding, bolt connection and other ways to connect with other structures,widely used in metallurgy, coal, cement, electric power, glass, mining, building materials, brick and other industries. Compared with other materials, it has a high cost performance.
Wear Steel Plate Packing
According to the properties and requirements of customers , Steel plate can hot-rolled, controlled rolling, normalizing, annealing, tempering, normalizing add tempering, modified such status delivery.
Packing Details:Bundle with steel strip
Delivery Details:Use trays to facilitate loading and unloading
Standard Export Seaworthy Package.Suit for all kinds of transport,or as required
Shipping Port:Tianjin/Shanghai/Qingdao,os as required
Container Size
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
20feet container load 25tons coils whose length is under 5.8m
40feet container load 25tons coils whose length is under 11.8m
